2W2P NORMALLY OPEN, BIDIRECTIONAL - PILOT OPERATED POPPET

Solenoid Operated Directional control valves allow fluid to flow into different paths from one or more sources. The direction of fluid flow control is controlled through a manual or electrical poppet.
2 Way 2 Position
Normally Open
Bidirectional - Pilot Operated Poppet
When de-energized, the valve allows flow from (1) to (2) or from (2) to (1).
When Energized, the valve blocks flow from (1) to (2) and blocks flow from (2) to (1).
Hardened parts for long life
Efficient wet-armature construction
Cartridges are voltage interchangeable
Manual override option
Industry common cavity
Unitized, molded coil design
Continuous duty rated solenoid
Optional coil voltage and terminations
720 hour salt spray protection
Optional "I" Coil: Weatherproof, Thermal Shock, Immersion Safe
Operation of Manual Override Option is located on the Product Details Technical Information sheet located on each individual parts page.
