DC MOTOR - PERMANENT MAGNET
- 12 Month Warranty from Purchase Date
- SCR Rated
- 20:1 Constant Torque speed range
- 1.0 Service Factor
- Rolled Steel Frame Construction
- Bolt-on Removable Base
- Double Shield Ball Bearings
- 1045 Steel Shaft
- Corrosion Resistant Hardware
- Countinuous (S1) Duty
- 40°C Ambient Temperature Range
- Installed up to 3300ft
- IP 54 (TEFC) & IP 5 (TENV) Rated
- Class F Insulation
- Class B Temperature Rise
| Image | Item # | MFR Number | HP | Frame | RPM | Voltage | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 5966064 | DC18-12-63-NV | 0.12 | 63B14 | 1800 | 12 V | $325.22 / EACH Usually ships in 1 day(s) | |||
| 5966065 | DC18-90-63-NV | 0.12 | 63B14 | 1800 | 90 V | $275.07 / EACH Usually ships in 1 day(s) | |||
| 5966060 | DC14-12-63-NV | 0.25 | 63B14 | 1800 | 12 V | $357.13 / EACH Usually ships in 1 day(s) | |||
| 5966061 | DC14-90-56-FC | 0.25 | 56C | 1800 | 90 V | $241.63 / EACH Usually ships in 1 day(s) | |||
| 5966062 | DC14-90-56-NV | 0.25 | 56C | 1800 | 90 V | $233.27 / EACH Usually ships in 1 day(s) | |||
| 5966063 | DC14-90-63-NV | 0.25 | 63B14 | 1800 | 90 V | $287.98 / EACH Usually ships in 1 day(s) | |||
| 5966059 | DC13-90-56-NV | 0.33 | 56C | 1800 | 90 V | $252.27 / EACH Usually ships in 1 day(s) | |||
| 5966055 | DC12-12-56-FC | 0.5 | 56C | 1800 | 12 V | $435.39 / EACH Usually ships in 1 day(s) | |||
| 5966057 | DC12-90-56-FC | 0.5 | 56C | 1800 | 90 V | $287.98 / EACH Usually ships in 1 day(s) | |||
| 5966058 | DC12-90-56-NV | 0.5 | 56C | 1800 | 90 V | $297.10 / EACH Usually ships in 1 day(s) | |||
| 5966056 | DC12-180-56-FC | 0.5 | 56C | 1800 | 180 V | $287.98 / EACH Usually ships in 1 day(s) | |||
| 5966070 | DC34-90-56-FC | 0.75 | 56C | 1800 | 90 V | $355.61 / EACH Usually ships in 1 day(s) | |||
| 5966069 | DC34-180-56-FC | 0.75 | 56C | 1800 | 180 V | $351.05 / EACH Usually ships in 1 day(s) | |||
| 5966066 | DC1-90-56-FC | 1 | 56C | 1800 | 90 V | $385.24 / EACH Usually ships in 1 day(s) | |||
| 5966054 | DC1-180-56-FC | 1 | 56C | 1800 | 180 V | $372.33 / EACH Usually ships in 1 day(s) |
