DIN Connector

DIN Connector

  • 5075 Maximum PSI
  • 26.4 Maximum GPM*
  • 3045 Maximum PSI on Tank Core
  • Mounting Surface: D03
  • IP65 Protection, Deutsch is IP69K Protection
  • UL, CSA, CE Approvals
  • Conduit Box Electrical Option has standard Indication Lights
  • DIN Connector Electrical Option Comes with DIN Connectors
  • All Models Ship with Mounting Bolts
  • Manual Override Standard
  • *Consult a Sales Representative for Application Assistance

*** Slide table left/right to view more ***

Item Order Qty. Mfr. Number Electrical Termination Inrush Amps Holding Amps
DSG-01-3C2-D12-N-7090 Yuken, Hydraulic, valve, D03, closed center, 12VDC, 5075 PSI, DIN connectors (connectors included), bolts included. Replaces Monarch 19258-Y. Replaces old DSG-01-3C2-D12-N-6090.

7040026

DSG-01-3C2-D12-N-7090 Yuken, Hydraulic, valv...

$162.96/each

In stock - Ships same day

DSG-01-3C2-D12-N-7090 12 VDC DIN - 2.45
DSG-01-3C2-D24-N-7090 Yuken, Hydraulic, valve, D03, closed center, 24VDC, 5075 PSI, DIN connectors (connectors included), bolts included. Replaces old DSG-01-3C2-D24-N-6090

7040033

DSG-01-3C2-D24-N-7090 Yuken, Hydraulic, valv...

$162.96/each

In stock - Ships same day

DSG-01-3C2-D24-N-7090 24 VDC DIN - 1.23
DSG-01-3C2-A120-N-7090 Yuken, Hydraulic, valve, D03, closed center, 120VAC, 5075 PSI, DIN connectors (connectors included), bolts included. Replaces old DSG-01-3C2-A120-N-6090

7040041

DSG-01-3C2-A120-N-7090 Yuken, Hydraulic, val...

$162.96/each

In stock - Ships same day

DSG-01-3C2-A120-N-7090 120 VAC DIN 1.78 0.31

*** Slide table left/right to view more ***

Page 1 of 1
