TOP MOUNT - STANDARD FLOW FILLER BREATHERS
- Bayonet zinc plated steel cap - large capacity
- Twist to lock removable cap breathes and filters air
- Concealed air vents allowing for outdoor applications
- Flute finger inserts for easy gripping (vented style only)
- 10 or 40 micron filtration (vented style only)
- Safety chain - prevents loss of cap
- Heavy duty Cork-Neoprene gasket provides a positive seal between flanges
- Zinc plated flange - bayonet flange (SAE J829)
- Strainer basket
- 4" long Nylon with solid dome bottom to prevent punchout
- 3" long Stainless Steel, 30 mesh
- Thread forming screws - prevents particles from entering reservoir during installation by forming threads rather than cutting them
| Image | Item # | Mfr. Number | Description | Cap Style | Micron Filtration | Max SCFM | Max GPM | Price | Order Qty. | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | 1232347 | 5201 | Non-Pressurized | Standard | 40 | 25 | 192 | $22.27 / EACH Usually ships in 3 day(s) |
| ||||
 | 1232348 | 5205 | Pressurized | Standard | 10 | 25 | 192 | $59.22 / EACH Usually ships in 3 day(s) |
| ||||
 | 1232349 | 5216 | Non-Pressurized | Standard | 40 | 25 | 192 | $26.33 / EACH Usually ships in 3 day(s) |
| ||||
 | 1232350 | 5220 | Non-Pressurized | Standard | 10 | 15 | 115 | $23.06 / EACH Usually ships in 3 day(s) |
| ||||
 | 1232351 | 5227 | Non-Pressurized | Non Vented | N/A | N/A | N/A | $25.13 / EACH Usually ships in 3 day(s) |
| ||||
 | 1232352 | 5232 | Non-Pressurized | Non Vented | N/A | N/A | N/A | $27.32 / EACH Usually ships in 3 day(s) |
| ||||
 | 1232399 | 5201LT | Non-Pressurized | Standard | 40 | 25 | 192 | $35.50 / EACH Usually ships in 3 day(s) |
| ||||
