N100 SERIES
- The N100 Series straight pattern needle valves with sight are ideally suited for vertical inline installation requiring controlled visible fluid metering
- Knurled wheel provides for smooth, accurate adjustments of flow rate
- Drip feedrate is adjustable from full orifice flow to complete shut-off
- Flow is readily visible through large sight window
- Pressure units supplied with non-vented sights
- Gravity feed valves are furnished with a vented sight chamber, provided by a split in the gasket above the sight glass
- 1/8, 1/4, 3/8 or 1/2 inch NPTF connections
- Available in either male or female connections
- Precision machined from brass bar stock
- Buna N seals
- Gauge glass sight
- Pipe threads are dryseal
- Maximum operating pressure 125 PSI to orifice
Image | Item # | Mfr. Number | Flow | Orifice | Inlet | Outlet | Hex | Total Length | Price | Order Qty. | ||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
1232781 | N102-01 | Gravity | 0.09" | 1/8" M | 1/8" M | 0.81" | 3.03" | $37.58 / EACH Usually ships in 3 day(s) |
| |||||
1232782 | N102-02 | Gravity | 0.09" | 1/4" M | 1/4" M | 0.81" | 3.41" | $39.00 / EACH Usually ships in 3 day(s) |
| |||||
1232783 | N102-03 | Gravity | 0.09" | 1/8" F | 1/8" F | 0.81" | 2.72" | $43.99 / EACH Usually ships in 3 day(s) |
| |||||
1232784 | N102-04 | Gravity | 0.09" | 1/4" F | 1/4" F | 0.81" | 2.97" | $37.36 / EACH Usually ships in 3 day(s) |
| |||||
1232785 | N102-12 | Pressure | 0.09" | 1/4" M | 1/4" M | 0.81" | 3.41" | $44.92 / EACH Usually ships in 3 day(s) |
| |||||
1232786 | N103-01 | Gravity | 0.11" | 3/8" M | 3/8" M | 0.94" | 3.56" | $55.56 / EACH Usually ships in 3 day(s) |
| |||||
1232787 | N103-02 | Gravity | 0.11" | 3/8" F | 3/8" F | 0.94" | 3.25" | $63.97 / EACH Usually ships in 3 day(s) |
| |||||
1232788 | N104-01 | Gravity | 0.15" | 1/2" M | 1/2" M | 1.06" | 3.94" | $70.44 / EACH Usually ships in 3 day(s) |
| |||||
1232789 | N104-02 | Gravity | 0.15" | 1/2" F | 1/2" F | 1.06" | 4.62" | $77.07 / EACH Usually ships in 3 day(s) |
|
