T Type Coils

Name: Trausch Dynamics
Address: 3727 Westgate Road, Grand Island, NE, 68803
Telephone: 800-323-5749

3/4" I.D.
2.38" Tall
28 Watts Nominal
Continous Duty ±10% Rated Voltage @ 120°F Ambient Temp, 80% of rated current @ room Temp
Temp Range -40°F to +392°F
18 Gauge Lead wires, 24" longs, 600 Volt rating, with strain relief
Glass filled polyester, resistant to moisture, caustic solutions, fungus and vibration
A.C. Coils include integrally molded full wave rectifiers which are rated for reverse voltage peaks of 1,000 volts maximum
A.C. Coils are rated 50/60 HZ

*** Slide table left/right to view more ***

Item	Order Qty.	Mfr. Number	Description	Voltage	Amp
7013788 TDL12 Delta Power, Standard Coil data T-Type...	$42.25/each In stock - Ships same day	TDL12	Dual Wire Lead	12 VDC	2.33
7013793 TDL24 Delta Power, Standard Coil data T-Type...	$43.75/each Usually ships in 11 weeks	TDL24	Dual Wire Lead	24 VDC	1.17
7013784 TDS12 Delta Power, Standard Coil data T-Type...	$70.01/each In stock - Ships same day	TDS12	Dual Wire Spade	12 VDC	2.33
7013891 TDS24 Delta Power, Standard Coil data T-Type...	$70.01/each Usually ships in 11 weeks	TDS24	Dual Wire Spade	24 VDC	1.17
7013790 THC11 Delta Power, Standard Coil data T-Type...	$70.01/each In stock - Ships same day	THC11	DIN 43650 (Hirschmann)	110 VAC	0.31
7013797 THC12 Delta Power, Standard Coil data T-Type...	$70.01/each In stock - Ships same day	THC12	DIN 43650 (Hirschmann)	12 VDC	2.33
7013893 THC22 Delta Power, Standard Coil data T-Type...	$70.01/each Usually ships in 11 weeks	THC22	DIN 43650 (Hirschmann)	220 VAC	0.15
7013799 THC24 Delta Power, Standard Coil data T-Type...	$70.01/each Usually ships in 11 weeks	THC24	DIN 43650 (Hirschmann)	24 VDC	1.17

*** Slide table left/right to view more ***

Page 1 of 1
