G605 SERIES
- The G605 Series front mount closed circuit sight gages provide front viewing of the fluid level clearly delineated by a redline on white background integral to the glass sight all secured within an aluminum body
- HIGH-LOW markings are stamped into the aluminum body
- Fluid level visible from front of gage (.50 inches wide)
- Viewing enhanced by redline on white background integral to sight glass
- Suitable for use with most hydraulic and machine lubricating oils
- Aluminum gage body and mounting bolts
- Buna N seals
- Borosilicate glass sight
- Zinc plated, steel locknuts
- CAUTION:
- Not recommended for use with water, steam, acidic fluids, caustic fluids and volatile fluids
- If aluminum construction is selected for a water application, anodizing is recommended
| Image | Item # | Mfr. Number | Mounting Centers | Width | Length | Seal | Viewing Window | Material | Price | Order Qty. | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1232575 | G605-03-A-1 | 3" | 0.9" | 4.62" | Buna | 1.5" x 0.5" | Aluminum | $23.79 / EACH Usually ships in 3 day(s) |
| ||||
| 1232576 | G605-03-A-3 | 3" | 0.9" | 4.62" | Viton | 1.5" x 0.5" | Aluminum | $27.11 / EACH Usually ships in 3 day(s) |
| ||||
| 1232577 | G605-04-A-1 | 4" | 0.9" | 5.62" | Buna | 2.5" x 0.5" | Aluminum | $25.43 / EACH Usually ships in 3 day(s) |
| ||||
| 1232578 | G605-05-B-1 | 5" | 0.9" | 6.62" | Buna | 3.5" x 0.5" | Brass | $167.00 / EACH Usually ships in 3 day(s) | |||||
| 1232579 | G605-05-Y-1 | 5" | 0.9" | 6.62" | Buna | 3.5" x 0.5" | Stainless Steel | $204.02 / EACH Usually ships in 3 day(s) | |||||
| 1232580 | G605-06-A-1 | 6" | 0.9" | 7.62" | Buna | 4.5" x 0.5" | Aluminum | $30.02 / EACH Usually ships in 3 day(s) |
| ||||
| 1232581 | G605-08-A-1 | 8" | 0.9" | 9.62" | Buna | 6.5" x 0.5" | Aluminum | $33.25 / EACH Usually ships in 3 day(s) |
| ||||
| 1232582 | G605-09-A-1 | 9" | 0.9" | 10.62" | Buna | 7.5" x 0.5" | Aluminum | $35.21 / EACH Usually ships in 3 day(s) |
| ||||
| 1232583 | G605-12-A-1 | 12" | 0.9" | 13.62" | Buna | 10.5" x 0.5" | Aluminum | $44.56 / EACH Usually ships in 3 day(s) |
| ||||
| 1232584 | G605-15-A-1 | 15" | 0.9" | 16.62" | Buna | 13.5" x 0.5" | Aluminum | $57.36 / EACH Usually ships in 3 day(s) |
| ||||
| 1232585 | G605-16-A-1 | 16" | 0.9" | 17.62" | Buna | 14.5" x 0.5" | Aluminum | $68.28 / EACH Usually ships in 3 day(s) |
| ||||
| 1232586 | G605-18-A-1 | 18" | 0.9" | 19.62" | Buna | 16.5" x 0.5" | Aluminum | $69.07 / EACH Usually ships in 3 day(s) |
| ||||
| 1232587 | G605-20-A-1 | 20" | 0.9" | 21.62" | Buna | 18.5" x 0.5" | Aluminum | $76.09 / EACH Usually ships in 3 day(s) |
| ||||
| 1232588 | G605-24-A-1 | 24" | 0.9" | 25.62" | Buna | 22.5" x 0.5" | Aluminum | $96.14 / EACH Usually ships in 3 day(s) |
| ||||
