RELIEF VALVES - DIRECT ACTING POPPET - DIFFERENTIAL-AREA, ADJUSTABLE
- Mechanical Pressure Control Valves
- Relief
- Direct Acting - Differential-Area, Adjustable
- The valve prevents flow from (2) to (1) until the set crack pressure is present at (2) is achieved
- The poppet then unseats allowing flow from (2) to (1) protecting the circuit from over pressurization
- Rapid response to pressure surges
- Low pressure rise
- Hardened poppet and seat for long life
- Aluminum knob and disc nut option
- Adjustment may be locked in place
- Adjustment prevents spring for going solid
- Hidden adjustment (tamper resistant option)
- Industry common cavity
| Image | Item # | Mfr. Number | GPM | PSI | Size | Seal | Spring Range | Adj. Style | Price | Order Qty. | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | 7015242 | DDRV-080-N-H-30 | 10 | 3000 | 8 | Buna | 50-3000 PSI | Hidden | $42.02 / EACH Usually ships in 7-8 week(s) |
| ||||
 | 7015243 | DDRV-080-N-K-4 | 10 | 3000 | 8 | Buna | 100-400 PSI | Knob | $47.13 / EACH Usually ships in 7-8 week(s) |
| ||||
 | 7015244 | DDRV-080-N-K-20 | 10 | 3000 | 8 | Buna | 300-2000 PSI | Knob | $47.13 / EACH Usually ships in 7-8 week(s) |
| ||||
 | 7015245 | DDRV-080-N-K-30 | 10 | 3000 | 8 | Buna | 1500-3000 PSI | Knob | $47.13 / EACH Usually ships in 7-8 week(s) |
| ||||
 | 7015246 | DDRV-080-N-S-4 | 10 | 3000 | 8 | Buna | 100-400 PSI | Screw | $44.29 / EACH Usually ships in 7-8 week(s) |
| ||||
 | 7015247 | DDRV-080-N-S-20 | 10 | 3000 | 8 | Buna | 300-2000 PSI | Screw | $44.29 / EACH Usually ships in 7-8 week(s) |
| ||||
 | 7015248 | DDRV-080-N-S-30 | 10 | 3000 | 8 | Buna | 1500-3000 PSI | Screw | $44.29 / EACH Usually ships in 7-8 week(s) |
| ||||
 | 7015249 | DDRV-100-N-H-6 | 20 | 3000 | 10 | Buna | 100-400 PSI | Hidden | $48.95 / EACH Usually ships in 7-8 week(s) |
| ||||
 | 7015250 | DDRV-100-N-H-20 | 20 | 3000 | 10 | Buna | 300-1000 PSI | Hidden | $48.95 / EACH Usually ships in 7-8 week(s) |
| ||||
 | 7015251 | DDRV-100-N-H-36 | 20 | 3000 | 10 | Buna | 300-2000 PSI | Hidden | $48.95 / EACH Usually ships in 7-8 week(s) |
| ||||
 | 7015252 | DDRV-100-N-K-6 | 20 | 3000 | 10 | Buna | 1500-3000 PSI | Hidden | $69.13 / EACH Usually ships in 7-8 week(s) |
| ||||
 | 7015253 | DDRV-100-N-K-20 | 20 | 3000 | 10 | Buna | 100-400 PSI | Knob | $69.13 / EACH Usually ships in 7-8 week(s) |
| ||||
 | 7015254 | DDRV-100-N-K-36 | 20 | 3000 | 10 | Buna | 300-1000 PSI | Knob | $69.13 / EACH Usually ships in 7-8 week(s) |
| ||||
 | 7015255 | DDRV-100-N-S-6 | 20 | 3000 | 10 | Buna | 300-2000 PSI | Knob | $49.45 / EACH Usually ships in 7-8 week(s) |
| ||||
 | 7015256 | DDRV-100-N-S-20 | 20 | 3000 | 10 | Buna | 1500-3000 PSI | Knob | $49.45 / EACH Usually ships in 7-8 week(s) |
| ||||
