G650 Series
- The G650 Series vented oil gauge utilizes an adapter union fitting to connect the base of the oil gauge to the reservoir
- This construction offers advantages when installing oil gauges in confined spaces by not requiring disassembly of the gauge base.
- The viewing window and shield do not rotate during installation of the oil gauge
- The viewing window has 360° adjustment for optimal orientation to view fluid after installation
- The sealing gaskets are contained on both their ID and OD to facilitate trouble-free assembly after on-site repositioning of the viewing window
- 0.69 inch SQ base machined from brass bar stock
- Adapter union fitting between reservoir and gauge base
- Reservoir thread connections of 1/8, 1/4 or 3/8 inch NPTF
- 0.39 inch wide viewing window, length varies from 1.33 to 7.33 inches depending on gauge selected
- 360° adjustment of viewing window
- Suitable for use with most machine lubricating oils
- Brass construction
- Buna N seals
- Borosilicate glass sight
- Maximum operating temperature of 250°F with standard Buna N seals
| Item | Order Qty. | Mfr. Number | Threads | Viewing Window |
|---|---|---|---|---|
|
$32.39/each |
G652-1 | 1/8" | 1.33" x 0.39" | |
|
$27.78/each |
G652-2 | 1/4" | 1.33" x 0.39" | |
|
$31.83/each |
G652-3 | 3/8" | 1.33" x 0.39" | |
|
$34.30/each |
G653-1 | 1/8" | 1.83" x 0.39" | |
|
$29.76/each |
G653-2 | 1/4" | 1.83" x 0.39" | |
|
$33.74/each |
G653-3 | 3/8" | 1.83" x 0.39" | |
|
$29.18/each |
G654-2 | 1/4" | 2.33" x 0.39" | |
|
$27.86/each |
G655-1 | 1/8" | 2.83" x 0.39" | |
|
$23.35/each |
G655-2 | 1/4" | 2.83" x 0.39" | |
|
$28.40/each |
G655-3 | 3/8" | 2.83" x 0.39" | |
|
$31.19/each |
G657-2 | 1/4" | 4.33" x 0.39" | |
|
$38.33/each |
G658-3 | 3/8" | 5.33" x 0.39" | |
|
$36.46/each |
G659-2 | 1/4" | 7.33" x 0.39" |
