VALVES
- Single load hold check
- Open center only
- Hard chrome plated spools, body is high strength cast iron, and seals are Buna "N"
- Compact construction (7.34" Long, 3.35" Wide)
- Balanced interchangeable spools
- Negative overlapping of the spool
- Max flow rate 10 GPM
- Max PSI at "P" port=3600 PSI
- Max PSI at "A" or "B" ports-4600 PSI
- Max PSI back-pressure at "T" port=430 PSI
- Max operating temperature=180°F
- Filter oil to 30 micron or better
- Leakage (1450 PSI, Temperature at 120°F)
Average: 0.366 In3/minute
Maximum: 0.732 In3/minute - Adjustable direct operated relief valve
- Handle can be mounted vertical or horizontal
| Image | Item # | Number of Spools | Spool Type | Ports | Pressure Range | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|---|---|
| 7153106 | 1 Spool | Cylinder Spool | #8 SAE O-Ring | 1300-3000 psi | $141.65 / EACH In stock - Ships same day | |||
 | 7153125 | 1 Spool | Motor Spool | #8 SAE O-Ring | 400-1300 psi | $141.65 / EACH In stock - Ships same day |
