5/8" Keyed Shaft Gear Motors 1.25" Long - SAE A, Aluminum, Honor

5/8" Keyed Shaft Gear Motors 1.25" Long - SAE A, Aluminum, Honor

  • Honor
  • SAE A
  • High-Strength Cast Iron Bodies
  • Hardened Alloy Gears and Shafts
  • Bronze Bearings
  • Buna Seals
  • 5/8" x 5/32 Keyed Shaft 1.25" Long
  • Bi-Directional Rotation

*** Slide table left/right to view more ***

Item Order Qty. Mfr. Number Shaft Keyway In3 Per Rev. Cont. PSI Max PSI RPM Range Working Ports Case Drain
2MM1U05 HONOR HYDRAULIC MOTOR, GEAR TYPE, SAE A 2-BOLT, 5/8" X 5/32" KEYED SHAFT (1.25 LONG), 0.30 CUBIC INCH DISPLACEMENT, 3500 PSI CONTINUOUS, Side Ported, 4200 PSI MAX, 600-4000 RPM RANGE, #12 SAE O-RING INLET & OUTLET, BI-DIRECTIONAL MOTOR, VITON SEALS, PRESSURE BALANCED MOTOR FOR HIGH EFFICIENCY, HONOR 2MM1U05

5947312

2MM1U05 HONOR HYDRAULIC MOTOR, GEAR TYPE, SA...

$313.28/each

Usually ships in 3 days

2MM1U05 5/8" 5/32" 0.30 3500 4200 600 - 4000 #12 SAE O-Ring Inlet & Outlet #6 SAE O-Ring
2MM1U06 HONOR HYDRAULIC MOTOR, GEAR TYPE, SAE A 2-BOLT, 5/8" X 5/32" KEYED SHAFT (1.25 LONG), 0.38 CUBIC INCH DISPLACEMENT, 3500 PSI CONTINUOUS, Side Ported, 4200 PSI MAX, 600-4000 RPM RANGE, #12 SAE O-RING INLET & OUTLET, BI-DIRECTIONAL MOTOR, VITON SEALS, PRESSURE BALANCED MOTOR FOR HIGH EFFICIENCY, HONOR 2MM1U06

5948550

2MM1U06 HONOR HYDRAULIC MOTOR, GEAR TYPE, SA...

$313.28/each

Usually ships in 3 days

2MM1U06 5/8" 5/32" 0.38 3500 4200 600 - 4000 #12 SAE O-Ring Inlet & Outlet #6 SAE O-Ring
2MM1U07 HONOR HYDRAULIC MOTOR, GEAR TYPE, SAE A 2-BOLT, 5/8" X 5/32" KEYED SHAFT (1.25 LONG), 0.43 CUBIC INCH DISPLACEMENT, 3500 PSI CONTINUOUS, Side Ported, 4200 PSI MAX, 600-4000 RPM RANGE, #12 SAE O-RING INLET & OUTLET, BI-DIRECTIONAL MOTOR, VITON SEALS, PRESSURE BALANCED MOTOR FOR HIGH EFFICIENCY, HONOR 2MM1U07

5947320

2MM1U07 HONOR HYDRAULIC MOTOR, GEAR TYPE, SA...

$313.28/each

Usually ships in 3 days

2MM1U07 5/8" 5/32" 0.43 3500 4200 600 - 4000 #12 SAE O-Ring Inlet & Outlet #6 SAE O-Ring
2MM1U08 HONOR HYDRAULIC MOTOR, GEAR TYPE, SAE A 2-BOLT, 5/8" X 5/32" KEYED SHAFT (1.25 LONG), 0.52 CUBIC INCH DISPLACEMENT, 3500 PSI CONTINUOUS, Side Ported, 4200 PSI MAX, 600-4000 RPM RANGE, #12 SAE O-RING INLET & OUTLET, BI-DIRECTIONAL MOTOR, VITON SEALS, PRESSURE BALANCED MOTOR FOR HIGH EFFICIENCY, HONOR 2MM1U08

5948551

2MM1U08 HONOR HYDRAULIC MOTOR, GEAR TYPE, SA...

$313.28/each

Usually ships in 3 days

2MM1U08 5/8" 5/32" 0.52 3500 4200 600 - 4000 #12 SAE O-Ring Inlet & Outlet #6 SAE O-Ring
2MM1U09 HONOR HYDRAULIC MOTOR, GEAR TYPE, SAE A 2-BOLT, 5/8" X 5/32" KEYED SHAFT (1.25 LONG), 0.58 CUBIC INCH DISPLACEMENT, 3500 PSI CONTINUOUS, Side Ported, 4200 PSI MAX, 600-4000 RPM RANGE, #12 SAE O-RING INLET & OUTLET, BI-DIRECTIONAL MOTOR, VITON SEALS, PRESSURE BALANCED MOTOR FOR HIGH EFFICIENCY, HONOR 2MM1U09

5947311

2MM1U09 HONOR HYDRAULIC MOTOR, GEAR TYPE, SA...

$313.28/each

Usually ships in 3 days

2MM1U09 5/8" 5/32" 0.58 3500 4200 600 - 4000 #12 SAE O-Ring Inlet & Outlet #6 SAE O-Ring
2MM1U11 HONOR HYDRAULIC MOTOR, GEAR TYPE, SAE A 2-BOLT, 5/8" X 5/32" KEYED SHAFT (1.25 LONG), 0.69 CUBIC INCH DISPLACEMENT, 3500 PSI CONTINUOUS, Side Ported, 4200 PSI MAX, 600-4000 RPM RANGE, #12 SAE O-RING INLET & OUTLET, BI-DIRECTIONAL MOTOR, VITON SEALS, PRESSURE BALANCED MOTOR FOR HIGH EFFICIENCY, HONOR 2MM1U11

5948552

2MM1U11 HONOR HYDRAULIC MOTOR, GEAR TYPE, SA...

$313.28/each

Usually ships in 3 days

2MM1U11 5/8" 5/32" 0.69 3500 4200 600 - 4000 #12 SAE O-Ring Inlet & Outlet #6 SAE O-Ring
2MM1U14 HONOR HYDRAULIC MOTOR, GEAR TYPE, SAE A 2-BOLT, 5/8" X 5/32" KEYED SHAFT (1.25 LONG), 0.85 CUBIC INCH DISPLACEMENT, 3500 PSI CONTINUOUS, Side Ported, 4200 PSI MAX, 600-4000 RPM RANGE, #12 SAE O-RING INLET & OUTLET, BI-DIRECTIONAL MOTOR, VITON SEALS, PRESSURE BALANCED MOTOR FOR HIGH EFFICIENCY, HONOR 2MM1U14

5947308

2MM1U14 HONOR HYDRAULIC MOTOR, GEAR TYPE, SA...

$313.28/each

Usually ships in 3 days

2MM1U14 5/8" 5/32" 0.85 3500 4200 600 - 4000 #12 SAE O-Ring Inlet & Outlet #6 SAE O-Ring
2MM1U16 HONOR HYDRAULIC MOTOR, GEAR TYPE, SAE A 2-BOLT, 5/8" X 5/32" KEYED SHAFT (1.25 LONG), 0.98 CUBIC INCH DISPLACEMENT, 3500 PSI CONTINUOUS, Side Ported, 4200 PSI MAX, 600-4000 RPM RANGE, #12 SAE O-RING INLET & OUTLET, BI-DIRECTIONAL MOTOR, VITON SEALS, PRESSURE BALANCED MOTOR FOR HIGH EFFICIENCY, HONOR 2MM1U16

5947322

2MM1U16 HONOR HYDRAULIC MOTOR, GEAR TYPE, SA...

$325.92/each

Usually ships in 3 days

2MM1U16 5/8" 5/32" 0.98 3500 4200 600 - 4000 #12 SAE O-Ring Inlet & Outlet #6 SAE O-Ring
2MM1U18 HONOR HYDRAULIC MOTOR, GEAR TYPE, SAE A 2-BOLT, 5/8" X 5/32" KEYED SHAFT (1.25 LONG), 1.10 CUBIC INCH DISPLACEMENT, 3500 PSI CONTINUOUS, Side Ported, 4200 PSI MAX, 600-4000 RPM RANGE, #12 SAE O-RING INLET & OUTLET, BI-DIRECTIONAL MOTOR, VITON SEALS, PRESSURE BALANCED MOTOR FOR HIGH EFFICIENCY, HONOR 2MM1U18

5948553

2MM1U18 HONOR HYDRAULIC MOTOR, GEAR TYPE, SA...

$325.92/each

Usually ships in 3 days

2MM1U18 5/8" 5/32" 1.10 3500 4200 600 - 4000 #12 SAE O-Ring Inlet & Outlet #6 SAE O-Ring
2MM1U20 HONOR HYDRAULIC MOTOR, GEAR TYPE, SAE A 2-BOLT, 5/8" X 5/32" KEYED SHAFT (1.25 LONG), 1.20 CUBIC INCH DISPLACEMENT, 3500 PSI CONTINUOUS, Side Ported, 4200 PSI MAX, 600-4000 RPM RANGE, #12 SAE O-RING INLET & OUTLET, BI-DIRECTIONAL MOTOR, VITON SEALS, PRESSURE BALANCED MOTOR FOR HIGH EFFICIENCY, HONOR 2MM1U20

5948554

2MM1U20 HONOR HYDRAULIC MOTOR, GEAR TYPE, SA...

$325.92/each

Usually ships in 3 days

2MM1U20 5/8" 5/32" 1.20 3500 4200 600 - 4000 #12 SAE O-Ring Inlet & Outlet #6 SAE O-Ring
2MM1U22 HONOR HYDRAULIC MOTOR, GEAR TYPE, SAE A 2-BOLT, 5/8" X 5/32" KEYED SHAFT (1.25 LONG), 1.31 CUBIC INCH DISPLACEMENT, 3000 PSI CONTINUOUS, Side Ported, 3000 PSI MAX, 600-2500 RPM RANGE, #12 SAE O-RING INLET & OUTLET, BI-DIRECTIONAL MOTOR, VITON SEALS, PRESSURE BALANCED MOTOR FOR HIGH EFFICIENCY, HONOR 2MM1U22

5948555

2MM1U22 HONOR HYDRAULIC MOTOR, GEAR TYPE, SA...

$325.92/each

Usually ships in 3 days

2MM1U22 5/8" 5/32" 1.31 3500 3000 600 - 2500 #12 SAE O-Ring Inlet & Outlet #6 SAE O-Ring
2MM1U24 HONOR HYDRAULIC MOTOR, GEAR TYPE, SAE A 2-BOLT, 5/8" X 5/32" KEYED SHAFT (1.25 LONG), 1.44 CUBIC INCH DISPLACEMENT, 2550 PSI CONTINUOUS, Side Ported, 3000 PSI MAX, 600-2500 RPM RANGE, #16 SAE O-RING INLET & OUTLET, BI-DIRECTIONAL MOTOR, VITON SEALS, PRESSURE BALANCED MOTOR FOR HIGH EFFICIENCY, HONOR 2MM1U24

5948556

2MM1U24 HONOR HYDRAULIC MOTOR, GEAR TYPE, SA...

$346.29/each

Usually ships in 3 days

2MM1U24 5/8" 5/32" 1.44 2550 3000 600 - 2500 #16 SAE O-Ring Inlet & Outlet #6 SAE O-Ring
2MM1U26 HONOR HYDRAULIC MOTOR, GEAR TYPE, SAE A 2-BOLT, 5/8" X 5/32" KEYED SHAFT (1.25 LONG), 1.53 CUBIC INCH DISPLACEMENT, 2550 PSI CONTINUOUS, Side Ported, 3000 PSI MAX, 600-2500 RPM RANGE, #16 SAE O-RING INLET & OUTLET, BI-DIRECTIONAL MOTOR, VITON SEALS, PRESSURE BALANCED MOTOR FOR HIGH EFFICIENCY, HONOR 2MM1U26

5947376

2MM1U26 HONOR HYDRAULIC MOTOR, GEAR TYPE, SA...

$346.29/each

Usually ships in 3 days

2MM1U26 5/8" 5/32" 1.53 2550 3000 600 - 2500 #16 SAE O-Ring Inlet & Outlet #6 SAE O-Ring
2MM1U28 HONOR HYDRAULIC MOTOR, GEAR TYPE, SAE A 2-BOLT, 5/8" X 5/32" KEYED SHAFT (1.25 LONG), 1.71 CUBIC INCH DISPLACEMENT, 2550 PSI CONTINUOUS, Side Ported, 3000 PSI MAX, 600-2500 RPM RANGE, #16 SAE O-RING INLET & OUTLET, BI-DIRECTIONAL MOTOR, VITON SEALS, PRESSURE BALANCED MOTOR FOR HIGH EFFICIENCY, HONOR 2MM1U28

5948557

2MM1U28 HONOR HYDRAULIC MOTOR, GEAR TYPE, SA...

$367.36/each

Usually ships in 3 days

2MM1U28 5/8" 5/32" 1.71 2550 3000 600 - 2500 #16 SAE O-Ring Inlet & Outlet #6 SAE O-Ring
2MM1U30 HONOR HYDRAULIC MOTOR, GEAR TYPE, SAE A 2-BOLT, 5/8" X 5/32" KEYED SHAFT (1.25 LONG), 1.84 CUBIC INCH DISPLACEMENT, 2550 PSI CONTINUOUS, Side Ported, 3000 PSI MAX, 600-2500 RPM RANGE, #16 SAE O-RING INLET & OUTLET, BI-DIRECTIONAL MOTOR, VITON SEALS, PRESSURE BALANCED MOTOR FOR HIGH EFFICIENCY, HONOR 2MM1U30

5947324

2MM1U30 HONOR HYDRAULIC MOTOR, GEAR TYPE, SA...

$367.36/each

Usually ships in 3 days

2MM1U30 5/8" 5/32" 1.84 2550 3000 600 - 2500 #16 SAE O-Ring Inlet & Outlet #6 SAE O-Ring

*** Slide table left/right to view more ***

Page  of 2
