M Type Coils

M Type Coils

  • 13/32" I.D.
  • 1.50" Tall
  • Fits MA, MC & MD 'Mini' Series Solenoid Valves
  • 20 Watts Nominal
  • Continous Duty ±10% Rated Voltage @ 70°F, Intermittent Duty for Higher Ambient Temp
  • Temp Range -40°F to +392°F
  • AC Coils are 50/60 HZ
  • Wires are 18 Gauge, 22"-24" Long, 600 Volt Rating & Strain Relief
  • Torque Coil Nuts to 3 ft. lbs. (36" in. lbs.)

*** Slide table left/right to view more ***

Item Order Qty. Mfr. Number Description Voltage Amp
MSS05 Delta Power Coil, 5 VDC, DIN 43650, 20.0 Watts, 4 Amps. Delta Power MSS05

7013706

MSS05 Delta Power Coil, 5 VDC, DIN 43650, 20...

$70.01/each

In stock - Ships same day

MSS05 Single 1/4" Spade 05 VDC 4
MDL24 Delta Power Coil, 24 VDC, Dual Wire Leads, 18 gauge wire, wires are 22"-24" long, 20.0 watts, 0.86 amps. Delta Power MDL24

7013506

MDL24 Delta Power Coil, 24 VDC, Dual Wire Le...

$70.01/each

In stock - Ships same day

MDL24 Double Wire Leads 24 VDC 0.86
MDS24 Delta Power Coil, 24 VDC, dual 1/4" spades, 20.0 watts, 0.86 amps. Delta Power MDS24

7013532

MDS24 Delta Power Coil, 24 VDC, dual 1/4" sp...

$70.01/each

In stock - Ships same day

MDS24 Double 1/4" Spades 24 VDC 0.86

*** Slide table left/right to view more ***

Page 1 of 1
