3" BORE
- Red Lion Agricultural Cylinders (Black in Color)
- 3000 PSI, Continuous Working Pressure
- Ductile Iron Pistons
- Hard Chrome Plated Rod
- High Tensile Steel, Zinc Plated Pins and Retainers
- Rod Wiper is Metal Encased Nitrile
- High Tensile Steel Tie-Rods
- Rod Seal, Tube Seal, & Piston Seal are 90 Durometer O-Ring with Back-Up Washers
- Piston Seal is Polyseal
- Catalog Page
| Image | Item # | Mfr. Number | Bore | Stroke | Rod Size | Retracted Dimension | Extended Dimension | Max. Column Load (lbs.) | Port Size | Pin Dia. | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 6050601 | 30TH08-125 | 3" | 8" | 1-1/4" | 18-1/4" | 26-1/4" | 21206 | #8 SAE Oring | 1" | $170.27 / EACH Usually ships in 5 day(s) | |||
| 6050600 | 30TH08-125ASAE | 3" | 8" ASAE | 1-1/4" | 20-1/4" | 28-1/4" | 21206 | #8 SAE Oring | 1" | $167.12 / EACH In stock - Ships same day | |||
| 6050604 | 30TH10-125 | 3" | 10" | 1-1/4" | 20-1/4" | 30-1/4" | 21206 | #8 SAE Oring | 1" | $182.93 / EACH In stock - Ships same day | |||
| 6050607 | 30TH12-125 | 3" | 12" | 1-1/4" | 22-1/4" | 34-1/4" | 21206 | #8 SAE Oring | 1" | $196.41 / EACH In stock - Ships same day | |||
| 6050610 | 30TH14-125 | 3" | 14" | 1-1/4" | 24-1/4" | 38-1/4" | 21206 | #8 SAE Oring | 1" | $207.95 / EACH In stock - Ships same day | |||
| 6050613 | 30TH16-150 | 3" | 16" | 1-1/2" | 26-1/4" | 42-1/4" | 21206 | #8 SAE Oring | 1" | $223.06 / EACH In stock - Ships same day | |||
| 6050612 | 30TH16-150ASAE | 3" | 16" ASAE | 1-1/2" | 31-1/2" | 47-1/2" | 21206 | #8 SAE Oring | 1-1/4" | $224.83 / EACH In stock - Ships same day | |||
| 6050616 | 30TH18-150 | 3" | 18" | 1-1/2" | 28-1/4" | 46-1/4" | 21206 | #8 SAE Oring | 1" | $235.77 / EACH In stock - Ships same day | |||
| 6050619 | 30TH20-150 | 3" | 20" | 1-1/2" | 30-1/4" | 50-1/4" | 21206 | #8 SAE Oring | 1" | $248.64 / EACH In stock - Ships same day | |||
| 6050622 | 30TH24-150 | 3" | 24" | 1-1/2" | 34-1/4" | 58-1/4" | 21206 | #8 SAE Oring | 1" | $273.57 / EACH In stock - Ships same day |
