  • Direct Interchange for Vickers V10
  • Balanced Vane Type
  • Fixed Displacement
  • Quieter operation than Gear Pump
  • High Efficiency
  • 100% Tested
  • *Not all vane pumps available are shown. Call and ask to speak to a sales represetative if the model you seek is not shown here.
*** Slide left / right to view more ***
ImageItem #Mfr. NumberRotationin3 Per Rev.GPM @ 1200 RPMMax. PSIMax. RPMInletOutletPort OrientationShaftPriceOrder Qty.
6303081V101P1S1A20CW0.21 GPM2500 PSI1800 RPM1" NPT#08 SAE O-RingOutlet Opposite Inlet3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft $242.43 / EACH
Ships next business day
6303082V101P2S1A20CW0.42 GPM2500 PSI1800 RPM1" NPT#08 SAE O-RingOutlet Opposite Inlet3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft $242.43 / EACH
Ships next business day
6303083V101P3S1A20CW0.63 GPM2500 PSI1800 RPM1" NPT#08 SAE O-RingOutlet Opposite Inlet3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft $242.43 / EACH
Ships next business day
6303084V101P4S1A20CW0.84 GPM2500 PSI1800 RPM1" NPT#08 SAE O-RingOutlet Opposite Inlet3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft $242.43 / EACH
Ships next business day
6303085V101P5S1A20CW15 GPM2500 PSI1800 RPM1" NPT#08 SAE O-RingOutlet Opposite Inlet3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft $242.43 / EACH
Ships next business day
6303086V101P6S1A20CW1.196 GPM2200 PSI1800 RPM1" NPT#08 SAE O-RingOutlet Opposite Inlet3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft $242.43 / EACH
Ships next business day
6303087V101P7S1A20CW1.397 GPM2000 PSI1800 RPM1" NPT#08 SAE O-RingOutlet Opposite Inlet3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft $242.43 / EACH
Ships next business day
6303088V101P1S1B20CW0.21 GPM2500 PSI1800 RPM1" NPT#08 SAE O-RingOutlet 90 Deg CCW from Inlet3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft $242.43 / EACH
Ships next business day
6303089V101P2S1B20CW0.42 GPM2500 PSI1800 RPM1" NPT#08 SAE O-RingOutlet 90 Deg CCW from Inlet3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft $242.43 / EACH
Ships next business day
6303090V101P3S1B20CW0.63 GPM2500 PSI1800 RPM1" NPT#08 SAE O-RingOutlet 90 Deg CCW from Inlet3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft $242.43 / EACH
Ships next business day
6303091V101P4S1B20CW0.84 GPM2500 PSI1800 RPM1" NPT#08 SAE O-RingOutlet 90 Deg CCW from Inlet3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft $242.43 / EACH
Ships next business day
6303092V101P5S1B20CW15 GPM2500 PSI1800 RPM1" NPT#08 SAE O-RingOutlet 90 Deg CCW from Inlet3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft $242.43 / EACH
Ships next business day
6303093V101P6S1B20CW1.196 GPM2200 PSI1800 RPM1" NPT#08 SAE O-RingOutlet 90 Deg CCW from Inlet3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft $242.43 / EACH
Ships next business day
6303094V101P7S1B20CW1.397 GPM2000 PSI1800 RPM1" NPT#08 SAE O-RingOutlet 90 Deg CCW from Inlet3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft $242.43 / EACH
Ships next business day
6303095V101P1S1C20CW0.21 GPM2500 PSI1800 RPM1" NPT#08 SAE O-RingOutlet In Line with Inlet3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft $242.43 / EACH
Ships next business day
   Page of 2
