SINGLE ACTING - TWO SPEED, ALUMINUM
- Two Speed
- Single Acting
- Aluminum Reservoir
- Metal reservoirs resist cracking
- Internal pressure relief valve for overload protection
- Good for use with cylinders and hydraulic tools or OEM applications
- Maximum Working Pressure: 10,000 PSI
- All pumps are shipped with oil in the tank
- *Oil Capacity varies by position. Pump can be mounted outlet up or down
- **Unit is equipped with a 7/16"-20 Tank Return Port
- BVA Catalog
| Image | Item # | BVA Model# | Usable Oil Capacity (in3) | Outlet Port | 1st Stage Pressure Rating/Oil Displacement Per Stroke (PSI/in3) | 2nd Stage Pressure Rating/Oil Displacement Per Stroke (PSI/in3) | Piston Stroke | Handle Operating Force | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | 8014037 | P352 | 21.4 | 3/8"-18 NPTF | 200 / 0.18 | 10,000 / 0.05 | 0.38" | 88 lbs | Add to cart to see price Usually ships in 1 day(s) | |||
 | 8012707 | P1000 | 61 | 3/8"-18 NPTF | 200 / 0.81 | 10,000 / 0.14 | 0.82" | 99 lbs | Add to cart to see price In stock - Ships same day | |||
 | 8013542 | P1000AD | 53-62 | 3/8"-18 NPTF | 200 / 0.81 | 10,000 / 0.14 | 0.82" | 99 lbs | Add to cart to see price Usually ships in 1 day(s) | |||
 | 8014329 | P2801 | 175 | 3/8"-18 NPTF | 200 / 0.18 | 10,000 / 0.05 | 0.82" | 99 lbs | Add to cart to see price Usually ships in 1 day(s) |
