COUNTERCLOCKWISE ROTATION
- Direct Interchange for Vickers V10
- Balanced Vane Type
- Fixed Displacement
- Quieter operation than Gear Pump
- High Efficiency
- 100% Tested
- *Not all vane pumps available are shown. Call and ask to speak to a sales represetative if the model you seek is not shown here.
| Image | Item # | Mfr. Number | Rotation | in3 Per Rev. | GPM @ 1200 RPM | Max. PSI | Max. RPM | Inlet | Outlet | Port Orientation | Shaft | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | 6303165 | V101P1S11A20L | CCW | 0.2 | 1 GPM | 2500 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet Opposite Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6303166 | V101P2S11A20L | CCW | 0.4 | 2 GPM | 2500 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet Opposite Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6303167 | V101P3S11A20L | CCW | 0.6 | 3 GPM | 2500 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet Opposite Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6303168 | V101P4S11A20L | CCW | 0.8 | 4 GPM | 2500 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet Opposite Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6303169 | V101P5S11A20L | CCW | 1 | 5 GPM | 2500 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet Opposite Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6303170 | V101P6S11A20L | CCW | 1.19 | 6 GPM | 2200 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet Opposite Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6303171 | V101P7S11A20L | CCW | 1.39 | 7 GPM | 2000 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet Opposite Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6303172 | V101P1S11B20L | CCW | 0.2 | 1 GPM | 2500 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6303173 | V101P2S11B20L | CCW | 0.4 | 2 GPM | 2500 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6303174 | V101P3S11B20L | CCW | 0.6 | 3 GPM | 2500 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6303175 | V101P4S11B20L | CCW | 0.8 | 4 GPM | 2500 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6303176 | V101P5S11B20L | CCW | 1 | 5 GPM | 2500 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6303177 | V101P6S11B20L | CCW | 1.19 | 6 GPM | 2200 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6303178 | V101P7S11B20L | CCW | 1.39 | 7 GPM | 2000 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6303179 | V101P1S11C20L | CCW | 0.2 | 1 GPM | 2500 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet In Line with Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day |
