RELIEF - PILOT OPERATED
- Mechanical Pressure Control Valves
- Relief
- Pilot Operated
- The valve blocks flow from (2) to (1) until sufficient pressure is present at (2) to force the pilot stage open and allowing the main stage to shift, opening (2) to (1)
- The cartridge offers smooth transition in response to load changes in common hydraulic circuits
- Hardened parts for long life
- Industry common cavity
| Image | Item # | Mfr. Number | GPM | PSI | Size | Seal | Options | Pressure Range | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | 7010969 | DE-RVP-00-4000 | 20 | 4000 | 7/8-14 | Buna | -0 | 100-4000 PSI | $51.00 / EACH In stock - Ships same day | |||
| 7010974 | DE-RVP-0K-4000 | 20 | 4000 | 7/8-14 | Buna | Override Knob | 100-4000 PSI | $59.50 / EACH Usually ships in 5 week(s). Expedite available. | |||
 | 7011671 | DE-RVP-V0-4000 | 20 | 4000 | 7/8-14 | Viton | -0 | 100-4000 PSI | $62.25 / EACH Usually ships in 5 week(s). Expedite available. | |||
 | 7011672 | DE-RVP-VK-4000 | 20 | 4000 | 7/8-14 | Viton | Override Knob | 100-4000 PSI | $65.50 / EACH Usually ships in 5 week(s). Expedite available. | |||
| 7010994 | DE-RWP-00-4000 | 15 | 4000 | 7/8-14 | Buna | -0 | 100-4000 PSI | $55.00 / EACH Usually ships in 5 week(s). Expedite available. | |||
 | 7011675 | DE-RWP-0K-4000 | 15 | 4000 | 7/8-14 | Buna | Override Knob | 100-4000 PSI | $62.50 / EACH Usually ships in 5 week(s). Expedite available. | |||
 | 7011676 | DE-RWP-V0-4000 | 15 | 4000 | 7/8-14 | Viton | -0 | 100-4000 PSI | $61.00 / EACH Usually ships in 5 week(s). Expedite available. | |||
 | 7011677 | DE-RWP-VI-4000 | 15 | 4000 | 7/8-14 | Viton | Internal Adjust | 100-4000 PSI | $61.00 / EACH Usually ships in 5 week(s). Expedite available. | |||
 | 7011678 | DE-RWP-VK-4000 | 15 | 4000 | 7/8-14 | Viton | Override Knob | 100-4000 PSI | $73.75 / EACH Usually ships in 5 week(s). Expedite available. | |||
 | 7011745 | HE-RWP-00-5000 | 40 | 5000 | 7/8-14 | Buna | -0 | 1000-5000 PSI | $66.00 / EACH Usually ships in 5 week(s). Expedite available. | |||
 | 7011746 | HE-RWP-0I-5000 | 40 | 5000 | 7/8-14 | Buna | Internal Adjust | 1000-5000 PSI | $66.00 / EACH Usually ships in 5 week(s). Expedite available. | |||
 | 7011747 | HE-RWP-0K-5000 | 40 | 5000 | 7/8-14 | Buna | Override Knob | 1000-5000 PSI | $73.50 / EACH Usually ships in 5 week(s). Expedite available. | |||
 | 7011748 | HE-RWP-V0-5000 | 40 | 5000 | 7/8-14 | Viton | -0 | 1000-5000 PSI | $72.00 / EACH Usually ships in 5 week(s). Expedite available. | |||
 | 7011749 | HE-RWP-VI-5000 | 40 | 5000 | 7/8-14 | Viton | Internal Adjust | 1000-5000 PSI | $72.00 / EACH Usually ships in 5 week(s). Expedite available. | |||
 | 7011750 | HE-RWP-VK-5000 | 40 | 5000 | 7/8-14 | Viton | Override Knob | 1000-5000 PSI | $79.50 / EACH Usually ships in 5 week(s). Expedite available. |
