Autoloader
- Carousel AutoLoader is the most comprehensive automatic prjectile loading, launching, & verifications system on the market today
- Designed for High-volume productions facilities
- This unit can be integrated into an automatic assembly line to clean hoses, tubes, or hydraulic assemblies
- It comes equipped with four cleaning modes to meet common cleaning procedures: Normal Clean, Air Purge +1 Projectile, Air Purge +2 Projectiles, & Adjustable Times Projectile Launcher without Verifications (perfect for cleaning tube bundles)
- These cleaning modes address the most common cleaning issues for purging large dirt particles or liquid residue form hydraulic lines
- The Built-in Programmable Logic Controller (PLC) effortlessly guides the user through the cleaning process & also logs fired & verified projectiles or faults
- Features & Benefits:
- Automatic projectile loading, firing & verification
- Removes internal contamination form hoses, tubes or pipes quickly and efficiently in a productjion environment
- Fully integratable in automated tube manufacturing processes
- Verifies projectile has exited hose, tube or pipe and ented the Containment Barrel along with expelled contamination
- Cleans hoses, tubes & pipes with an internal diameter of 1/4" (6mm) through 1" (25mm)
- Easy change-out between 10 Hopper Box options, each handing one projectile size from 6mm to 33mm in diameter
- Foot pedal firing device and/or hand held firing device options
- Containment Barrel made of plastic and has a stainless steel chute assembly with green, yellow, and red lights to indicate system and projectile mode (read, firing, verified)
| Item | Order Qty. | Mfr. Number | Item |
|---|---|---|---|
|
$27,452.81/each |
UC-CAL-MS | Carousel Autoloaders | |
|
$2,560.81/each |
UC-CAL-HH | 2" Hand Held Launcher | |
|
$2,361.95/each |
UC-HB-07 | Hopper Box for 7mm Projectiles | |
|
$2,361.95/each |
UC-HB-10 | Hopper Box for 10mm Projectiles | |
|
$2,361.95/each |
UC-HB-12 | Hopper Box for 12mm Projectiles | |
|
$2,361.95/each |
UC-HB-14 | Hopper Box for 14mm Projectiles | |
|
$2,361.95/each |
UC-HB-16 | Hopper Box for 16mm Projectiles | |
|
$2,361.95/each |
UC-HB-18 | Hopper Box for 18mm Projectiles | |
|
$2,361.95/each |
UC-HB-20/22 | Hopper Box for 20mm & 22mm Projectiles | |
|
$3,038.18/each |
UC-HB-26 | Hopper Box for 24mm & 26mm Projectiles | |
|
$3,038.18/each |
UC-HB-33 | Hopper Box for 28mm, 30mm & 30mm Projectiles |
