Horizontal Steel Tanks (Extra Large Capacity)

Horizontal Steel Tanks (Extra Large Capacity)

  • Will Run (3) Double-Acting Cylinders, Power-Up, Power-Down, Power Unit
  • Load Holding On Ports "AC" & "AR" & "BC" & "BR" & "CC" & "CR"
  • Horizontal Steel Tank (8.00" Square)
  • #6 SAE O-Ring Ports
  • Relief Set At 3200 PSI, Adjustable from 1800 PSI to 3200 PSI
  • Integral Pressure Port Check Valve
  • Heavy Duty Ball-Bearing Motor
  • Heavy Duty Motor Start Switch
  • Made in the USA
  • Hand Control

*** Slide table left/right to view more ***

Item Order Qty. Mfr. Number Tank Capacity Overall Tank Length
D203T-TRPL-34-32 - MTE 12 VDC Power Unit, Hydraulic Circuit: (3) Double Acting Cylinders, Load Holding on ALL Ports, 2.50 Gallon Capacity, Horizontal Steel Tank, Ports are #6 SAE O-Ring, Relief is set at 3200 PSI (Adjustable From 1750 PSI to 3200 PSI), Integral Pressure Port Check Valve, Heavy-Duty Ball-Bearing Motor, Heavy-Duty Motor Start Switch. Also Replaces MTE D202T-TRPL-34-32.

6111665

D203T-TRPL-34-32 - MTE 12 VDC Power Unit, Hy...

$1,304.84/asmb

In stock - Ships same day

D203T-TRPL-34-32 2.50 Gallons 13.25"
D203T-TRPL-35-32 - MTE 12 VDC Power Unit, Hydraulic Circuit: (3) Double Acting Cylinders, Load Holding on ALL Ports, 3.5 Gallon Capacity, Horizontal Steel Tank, Ports are #6 SAE O-Ring, Relief is set at 3200 PSI (Adjustable From 1750 PSI to 3200 PSI), Integral Pressure Port Check Valve, Heavy-Duty Ball-Bearing Motor, Heavy-Duty Motor Start Switch. Also Replaces MTE D202T-TRPL-35-32.

6111667

D203T-TRPL-35-32 - MTE 12 VDC Power Unit, Hy...

$1,354.48/asmb

In stock - Ships same day

D203T-TRPL-35-32 3.50 Gallons 17.88"

*** Slide table left/right to view more ***

Page 1 of 1
