SINGLE ACTING - HIGH TONNAGE
- Cylinders are burnish rolled for a smooth precision mirror finish
- Rod wiper seals out dirt and contamination
- Base mounting holes on all models
- Load return
- High strength steel construction from gun drilled solid bar
- High flow 3/8" NPTF couplers
- Polyurethane cup seal provides optimum performance
- Industrial hard chrome plated rod helps prevent rust and corrosion
- Solid steel cylinder body provides strength for high tonnage applications
- High cycle applications
- Fixturing
- Rugged Applications
- Collar threads
- Removable saddles
- Larger upper and lower bearings to resist side loading
- Maximum Working Pressure: 10,000 PSI / 700 bar
- CH38F High Flow Coupler and Dust Cap Standard (*Except where noted, CRZ14F)
- **Cylinder is Equipped with a Carrying Handle
- Safety Practices: Good industry practice recommends not exceeding 80% of maximum rated capacities of all products.
- BVA Catalog
| Image | Item # | BVA Model# | Capacity (Tons) | Bore | Stroke | Rod Dia. | Effective Area (in2) | Oil Capacity (in3) | Collapsed Height | Extended Height | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 8013491 | HG10002 | 100 Ton | 5.12" | 1.97" | 3.74" | 20.57 | 40.5 | 7.17" | 9.14" | Add to cart to see price Usually ships in 1 day(s) | |||
| 8013492 | HG10004 | 100 Ton | 5.12" | 3.94" | 3.74" | 20.57 | 81 | 9.13" | 13.07" | Add to cart to see price Usually ships in 1 day(s) | |||
| 8013493 | HG10006 | 100 Ton | 5.12" | 5.91" | 3.74" | 20.57 | 121.5 | 11.1" | 17.01" | Add to cart to see price Usually ships in 1 day(s) | |||
| 8013494 | HG10008 | 100 Ton | 5.12" | 7.87" | 3.74" | 20.57 | 161.99 | 13.07" | 20.94" | Add to cart to see price Usually ships in 1 day(s) | |||
| 8013495 | HG10010 | 100 Ton | 5.12" | 9.84" | 3.74" | 20.57 | 202.49 | 15.04" | 24.88" | Add to cart to see price Usually ships in 1 day(s) | |||
| 8013496 | HG10012 | 100 Ton | 5.12" | 11.81" | 3.74" | 20.57 | 242.99 | 17.01" | 28.82" | Add to cart to see price Usually ships in 1 day(s) | |||
| 8013497 | HG15002 | 150 Ton | 6.22" | 1.97" | 4.33" | 30.43 | 59.89 | 7.72" | 9.69" | Add to cart to see price Usually ships in 1 day(s) | |||
| 8013498 | HG15004 | 150 Ton | 6.22" | 3.94" | 4.33" | 30.43 | 119.78 | 9.69" | 13.62" | Add to cart to see price Usually ships in 1 day(s) | |||
 | 8013272 | HG15006 | 150 Ton | 6.22" | 5.91" | 4.33" | 30.43 | 181.75 | 11.65" | 17.56" | Add to cart to see price Usually ships in 1 day(s) | |||
| 8013499 | HG15008 | 150 Ton | 6.22" | 7.87" | 4.33" | 30.43 | 239.57 | 13.62" | 21.5" | Add to cart to see price Usually ships in 1 day(s) | |||
| 8013500 | HG15010 | 150 Ton | 6.22" | 9.84" | 4.33" | 30.43 | 299.46 | 15.59" | 25.43" | Add to cart to see price Usually ships in 1 day(s) | |||
| 8013501 | HG15012 | 150 Ton | 6.22" | 11.81" | 4.33" | 30.43 | 359.35 | 17.56" | 29.37" | Add to cart to see price Usually ships in 1 day(s) |
