DUAL PORTED 5/8" 9-TOOTH SPLINED GEAR PUMPS 1.25" LONG - SAE A, ALUMINUM, HONOR
- Honor Hydraulic Gear Pumps
- 2 Bolt SAE A Mount
- 3-1/4" pilot
- 5/8" 9-Tooth Splined shaft
- Dual Ports SAE O-Ring
- Similar to Prince SP20 Series
| Image | Item # | Mfr. Number | Rotation | Shaft | In3 Per Rev. | GPM @ RPM 1750 | Cont. PSI | Max PSI | RPM Range | Suction Port Threads | Pressure Port Threads | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 5947830 | 2GG2U04RE | CW | 5/8" 9-T Spline | 0.24 | 1.82 | 3500 | 4200 | 600-4000 | #12 SAE SIDE #16 SAE REAR | #10 SAE SIDE #12 SAE REAR | $330.26 / EACH Usually ships in 3 day(s) | |||
| 5947831 | 2GG2U04LE | CCW | 5/8" 9-T Spline | 0.24 | 1.82 | 3500 | 4200 | 600-4000 | #12 SAE SIDE #16 SAE REAR | #10 SAE SIDE #12 SAE REAR | $330.26 / EACH Usually ships in 3 day(s) | |||
| 5947832 | 2GG2U05RE | CW | 5/8" 9-T Spline | 0.3 | 2.27 | 3500 | 4200 | 600-4000 | #12 SAE SIDE #16 SAE REAR | #10 SAE SIDE #12 SAE REAR | $330.26 / EACH Usually ships in 3 day(s) | |||
| 5947833 | 2GG2U05LE | CCW | 5/8" 9-T Spline | 0.3 | 2.27 | 3500 | 4200 | 600-4000 | #12 SAE SIDE #16 SAE REAR | #10 SAE SIDE #12 SAE REAR | $330.26 / EACH In stock - Ships same day | |||
| 5947834 | 2GG2U06RE | CW | 5/8" 9-T Spline | 0.37 | 2.8 | 3500 | 4200 | 600-4000 | #12 SAE SIDE #16 SAE REAR | #10 SAE SIDE #12 SAE REAR | $330.26 / EACH Usually ships in 3 day(s) | |||
| 5947835 | 2GG2U06LE | CCW | 5/8" 9-T Spline | 0.37 | 2.8 | 3500 | 4200 | 600-4000 | #12 SAE SIDE #16 SAE REAR | #10 SAE SIDE #12 SAE REAR | $330.26 / EACH Usually ships in 3 day(s) | |||
| 5947836 | 2GG2U07RE | CW | 5/8" 9-T Spline | 0.43 | 3.26 | 3500 | 4200 | 600-4000 | #12 SAE SIDE #16 SAE REAR | #10 SAE SIDE #12 SAE REAR | $330.26 / EACH Usually ships in 3 day(s) | |||
| 5947837 | 2GG2U07LE | CCW | 5/8" 9-T Spline | 0.43 | 3.26 | 3500 | 4200 | 600-4000 | #12 SAE SIDE #16 SAE REAR | #10 SAE SIDE #12 SAE REAR | $330.26 / EACH Usually ships in 3 day(s) | |||
| 5947838 | 2GG2U08RE | CW | 5/8" 9-T Spline | 0.52 | 3.94 | 3500 | 4200 | 600-4000 | #12 SAE SIDE #16 SAE REAR | #10 SAE SIDE #12 SAE REAR | $330.26 / EACH Usually ships in 3 day(s) | |||
| 5947839 | 2GG2U08LE | CCW | 5/8" 9-T Spline | 0.52 | 3.94 | 3500 | 4200 | 600-4000 | #12 SAE SIDE #16 SAE REAR | #10 SAE SIDE #12 SAE REAR | $330.26 / EACH Usually ships in 3 day(s) | |||
| 5947840 | 2GG2U09RE | CW | 5/8" 9-T Spline | 0.58 | 4.39 | 3500 | 4200 | 600-4000 | #12 SAE SIDE #16 SAE REAR | #10 SAE SIDE #12 SAE REAR | $330.26 / EACH Usually ships in 3 day(s) | |||
| 5947841 | 2GG2U09LE | CCW | 5/8" 9-T Spline | 0.58 | 4.39 | 3500 | 4200 | 600-4000 | #12 SAE SIDE #16 SAE REAR | #10 SAE SIDE #12 SAE REAR | $330.26 / EACH Usually ships in 3 day(s) | |||
| 5947842 | 2GG2U11RE | CW | 5/8" 9-T Spline | 0.69 | 5.23 | 3500 | 4200 | 600-4000 | #12 SAE SIDE #16 SAE REAR | #10 SAE SIDE #12 SAE REAR | $330.26 / EACH Usually ships in 3 day(s) | |||
| 5947843 | 2GG2U11LE | CCW | 5/8" 9-T Spline | 0.69 | 5.23 | 3500 | 4200 | 600-4000 | #12 SAE SIDE #16 SAE REAR | #10 SAE SIDE #12 SAE REAR | $330.26 / EACH Usually ships in 3 day(s) | |||
| 5947844 | 2GG2U14RE | CW | 5/8" 9-T Spline | 0.85 | 6.44 | 3500 | 4200 | 600-4000 | #12 SAE SIDE #16 SAE REAR | #10 SAE SIDE #12 SAE REAR | $340.31 / EACH Usually ships in 3 day(s) |
