17 GPM 12 VDC Electric Directional Valve w/ Control Kits

17 GPM 12 VDC Electric Directional Valve w/ Control Kits

  • Used to control direction of cylinders or motors, depending on application
  • Can be used on most mobile equipment, including ag equipment, tow trucks, tractors, and bale beds.
  • 17 GPM Maximum Flow
  • 3600 PSI Max at "P" Port
  • 4600 PSI Max at "A" or "B" Ports
  • 290 PSI Max back-pressure at "T" Port
  • Adjustable Relief Valve 1300-3000 PSI
  • Relief set at 2200 PSI
  • DIN 12 VDC Coils, 34 Watts, 2.80 Amps
  • Switch box features easily adjustable bail mount
  • Heavy duty long bat handle momentary switches
  • Switches are color coded
  • Switch box has 3' wiring harness and 6' power cable
  • 18 gauge shielded wire
  • IP69 Deutsch Connectors
  • IP65 Coil Connectors
  • IP65 DIN Connectors
  • 10 Amp fuse kit
  • 20' wiring harness
  • 3' Valve harness

*** Slide table left/right to view more ***

Item Order Qty. Sections # of Switches Circuit Tank & Pressure Ports Work Ports Power Beyond Switch Colors
Used to control direction of cylinders or motors depending on application. Can be used on mobile equipment including ag equipment, tow trucks, tractors and Bale Beds. All Kits Include: (1) 1-switch box with wiring harness, (10) 7.5" cable ties, (1) 10 Amp fuse kit, (1) 20' wiring harness, (1) DIN valve wiring harness, & (1) 17 GPM Valve. Electrical Specifications: 4.76"x2.60"x1.40" black switch box, easily adjustable bail mount, heavy duty 10 Amp switch, momentary switches (on)-off-(on), long bat handle switch for easy actuation, switches are color coded, switch box has 3' wiring harness, switch box has 6' power cable, shielded wire, 18 gauge wires, IP69 Deutsch Connectors, IP65 Coil Connections, IP65 DIN Connectors, 10 Amp fuse kit with instructions, 20' wiring harness, 3' valve harness. Valve Specifications: 17 GPM nominal flow rate, 3600 PSI max at "P" Port, 4600 PSI max at "A" or "B" ports, 290 PSI max back-pressure at "T" port, adjustable relief valve 1300-3000 PSI, Relief set at 2200 PSI, DIN 12 VDC Coils, 34 Watts, 2.80 Amps.

9504512

Used to control direction of cylinders or mo...

$934.74/each

Usually ships in 1 day

Double Acting Cylinder 1 Open Center #10 SAE #10 SAE Yes Red
Used to control direction of cylinders or motors depending on application. Can be used on mobile equipment including ag equipment, tow trucks, tractors and Bale Beds. All Kits Include: (1) 1-switch box with wiring harness, (10) 7.5" cable ties, (1) 10 Amp fuse kit, (1) 20' wiring harness, (1) DIN valve wiring harness, & (1) 17 GPM Valve. Electrical Specifications: 4.76"x2.60"x1.40" black switch box, easily adjustable bail mount, heavy duty 10 Amp switch, momentary switches (on)-off-(on), long bat handle switch for easy actuation, switches are color coded, switch box has 3' wiring harness, switch box has 6' power cable, shielded wire, 18 gauge wires, IP69 Deutsch Connectors, IP65 Coil Connections, IP65 DIN Connectors, 10 Amp fuse kit with instructions, 20' wiring harness, 3' valve harness. Valve Specifications: 17 GPM nominal flow rate, 3600 PSI max at "P" Port, 4600 PSI max at "A" or "B" ports, 290 PSI max back-pressure at "T" port, adjustable relief valve 1300-3000 PSI, Relief set at 2200 PSI, DIN 12 VDC Coils, 34 Watts, 2.80 Amps.

9504513

Used to control direction of cylinders or mo...

$935.90/each

Usually ships in 1 day

Double Acting Cylinder 1 Closed Center #10 SAE #10 SAE Yes Red
Used to control direction of cylinders or motors depending on application. Can be used on mobile equipment including ag equipment, tow trucks, tractors and Bale Beds. All Kits Include: (1) 2-switch box with wiring harness, (10) 7.5" cable ties, (1) 10 Amp fuse kit, (1) 20' wiring harness, (1) DIN valve wiring harness, & (1) 17 GPM Valve. Electrical Specifications: 4.76"x2.60"x1.40" black switch box, easily adjustable bail mount, heavy duty 10 Amp switch, momentary switches (on)-off-(on), long bat handle switch for easy actuation, switches are color coded, switch box has 3' wiring harness, switch box has 6' power cable, shielded wire, 18 gauge wires, IP69 Deutsch Connectors, IP65 Coil Connections, IP65 DIN Connectors, 10 Amp fuse kit with instructions, 20' wiring harness, 3' valve harness. Valve Specifications: 17 GPM nominal flow rate, 3600 PSI max at "P" Port, 4600 PSI max at "A" or "B" ports, 290 PSI max back-pressure at "T" port, adjustable relief valve 1300-3000 PSI, Relief set at 2200 PSI, DIN 12 VDC Coils, 34 Watts, 2.80 Amps.

9504448

Used to control direction of cylinders or mo...

$1,451.21/each

Usually ships in 1 day

Double Acting Cylinder 2 Open Center #10 SAE #10 SAE Yes Red / White
Used to control direction of cylinders or motors depending on application. Can be used on mobile equipment including ag equipment, tow trucks, tractors and Bale Beds. All Kits Include: (1) 2-switch box with wiring harness, (10) 7.5" cable ties, (1) 10 Amp fuse kit, (1) 20' wiring harness, (1) DIN valve wiring harness, & (1) 17 GPM Valve. Electrical Specifications: 4.76"x2.60"x1.40" black switch box, easily adjustable bail mount, heavy duty 10 Amp switch, momentary switches (on)-off-(on), long bat handle switch for easy actuation, switches are color coded, switch box has 3' wiring harness, switch box has 6' power cable, shielded wire, 18 gauge wires, IP69 Deutsch Connectors, IP65 Coil Connections, IP65 DIN Connectors, 10 Amp fuse kit with instructions, 20' wiring harness, 3' valve harness. Valve Specifications: 17 GPM nominal flow rate, 3600 PSI max at "P" Port, 4600 PSI max at "A" or "B" ports, 290 PSI max back-pressure at "T" port, adjustable relief valve 1300-3000 PSI, Relief set at 2200 PSI, DIN 12 VDC Coils, 34 Watts, 2.80 Amps.

9504449

Used to control direction of cylinders or mo...

$1,452.38/each

Usually ships in 1 day

Double Acting Cylinder 2 Closed Center #10 SAE #10 SAE Yes Red / White
Used to control direction of cylinders or motors depending on application. Can be used on mobile equipment including ag equipment, tow trucks, tractors and Bale Beds. All Kits Include: (1) 3-switch box with wiring harness, (10) 7.5" cable ties, (1) 10 Amp fuse kit, (1) 20' wiring harness, (1) DIN valve wiring harness, & (1) 17 GPM Valve. Electrical Specifications: 4.76"x2.60"x1.40" black switch box, easily adjustable bail mount, heavy duty 10 Amp switch, momentary switches (on)-off-(on), long bat handle switch for easy actuation, switches are color coded, switch box has 3' wiring harness, switch box has 6' power cable, shielded wire, 18 gauge wires, IP69 Deutsch Connectors, IP65 Coil Connections, IP65 DIN Connectors, 10 Amp fuse kit with instructions, 20' wiring harness, 3' valve harness. Valve Specifications: 17 GPM nominal flow rate, 3600 PSI max at "P" Port, 4600 PSI max at "A" or "B" ports, 290 PSI max back-pressure at "T" port, adjustable relief valve 1300-3000 PSI, Relief set at 2200 PSI, DIN 12 VDC Coils, 34 Watts, 2.80 Amps.

9504472

Used to control direction of cylinders or mo...

$1,963.39/each

Usually ships in 1 day

Double Acting Cylinder 3 Open Center #10 SAE #10 SAE Yes Red / White / Blue
Used to control direction of cylinders or motors depending on application. Can be used on mobile equipment including ag equipment, tow trucks, tractors and Bale Beds. All Kits Include: (1) 3-switch box with wiring harness, (10) 7.5" cable ties, (1) 10 Amp fuse kit, (1) 20' wiring harness, (1) DIN valve wiring harness, & (1) 17 GPM Valve. Electrical Specifications: 4.76"x2.60"x1.40" black switch box, easily adjustable bail mount, heavy duty 10 Amp switch, momentary switches (on)-off-(on), long bat handle switch for easy actuation, switches are color coded, switch box has 3' wiring harness, switch box has 6' power cable, shielded wire, 18 gauge wires, IP69 Deutsch Connectors, IP65 Coil Connections, IP65 DIN Connectors, 10 Amp fuse kit with instructions, 20' wiring harness, 3' valve harness. Valve Specifications: 17 GPM nominal flow rate, 3600 PSI max at "P" Port, 4600 PSI max at "A" or "B" ports, 290 PSI max back-pressure at "T" port, adjustable relief valve 1300-3000 PSI, Relief set at 2200 PSI, DIN 12 VDC Coils, 34 Watts, 2.80 Amps.

9504473

Used to control direction of cylinders or mo...

$1,964.55/each

Usually ships in 1 day

Double Acting Cylinder 3 Closed Center #10 SAE #10 SAE Yes Red / White / Blue
Used to control direction of cylinders or motors depending on application. Can be used on mobile equipment including ag equipment, tow trucks, tractors and Bale Beds. All Kits Include: (1) 4-switch box with wiring harness, (10) 7.5" cable ties, (1) 10 Amp fuse kit, (1) 20' wiring harness, (1) DIN valve wiring harness, & (1) 17 GPM Valve. Electrical Specifications: 4.76"x2.60"x1.40" black switch box, easily adjustable bail mount, heavy duty 10 Amp switch, momentary switches (on)-off-(on), long bat handle switch for easy actuation, switches are color coded, switch box has 3' wiring harness, switch box has 6' power cable, shielded wire, 18 gauge wires, IP69 Deutsch Connectors, IP65 Coil Connections, IP65 DIN Connectors, 10 Amp fuse kit with instructions, 20' wiring harness, 3' valve harness. Valve Specifications: 17 GPM nominal flow rate, 3600 PSI max at "P" Port, 4600 PSI max at "A" or "B" ports, 290 PSI max back-pressure at "T" port, adjustable relief valve 1300-3000 PSI, Relief set at 2200 PSI, DIN 12 VDC Coils, 34 Watts, 2.80 Amps.

9504488

Used to control direction of cylinders or mo...

$2,493.19/each

Usually ships in 1 day

Double Acting Cylinder 4 Open Center #10 SAE #10 SAE Yes Red / White / Blue / Green
Used to control direction of cylinders or motors depending on application. Can be used on mobile equipment including ag equipment, tow trucks, tractors and Bale Beds. All Kits Include: (1) 4-switch box with wiring harness, (10) 7.5" cable ties, (1) 10 Amp fuse kit, (1) 20' wiring harness, (1) DIN valve wiring harness, & (1) 17 GPM Valve. Electrical Specifications: 4.76"x2.60"x1.40" black switch box, easily adjustable bail mount, heavy duty 10 Amp switch, momentary switches (on)-off-(on), long bat handle switch for easy actuation, switches are color coded, switch box has 3' wiring harness, switch box has 6' power cable, shielded wire, 18 gauge wires, IP69 Deutsch Connectors, IP65 Coil Connections, IP65 DIN Connectors, 10 Amp fuse kit with instructions, 20' wiring harness, 3' valve harness. Valve Specifications: 17 GPM nominal flow rate, 3600 PSI max at "P" Port, 4600 PSI max at "A" or "B" ports, 290 PSI max back-pressure at "T" port, adjustable relief valve 1300-3000 PSI, Relief set at 2200 PSI, DIN 12 VDC Coils, 34 Watts, 2.80 Amps.

9504489

Used to control direction of cylinders or mo...

$2,494.35/each

Usually ships in 1 day

Double Acting Cylinder 4 Closed Center #10 SAE #10 SAE Yes Red / White / Blue / Green

*** Slide table left/right to view more ***
