HYDRAULICVALVESDIRECTIONAL CONTROL VALVESMANUALLY CONTROLLED

PRINCE - SV SERIES, 12 GPM MANUAL DIRECTIONAL CONTROL STACK VALVES

  • 1 to 8 work sections per valve stack
  • Load hold check on each section
  • Open or closed center capability
  • Hard chrome plated spools
  • Body is high strength cast iron
  • Compact construction
  • Seals are Buna "N"
  • Parallet circuit
  • Wide selection of inlets, outlets & work sections
  • Max flow rate 12 GPM
  • Max PSI = 3000 PSI
  • Max PSI back-pressure at "T" port = 500 PSI
  • Max operating temperature = 180°F
  • Filter oil to 25 micron or better
  • Adjustable differential poppet style relief valve
  • Port relief option
  • Anti-cavitation option
  • Combination port relief/anti-cavitation option
  • Power beyond capability
  • Reversible handle
PRINCE - SV SERIES, 12 GPM MANUAL DIRECTIONAL CONTROL STACK VALVES
