CLOCKWISE ROTATION
- Direct Interchange for Vickers V20
- Balanced Vane Type
- Fixed Displacement
- Quieter operation than Gear Pump
- High Efficiency
- 100% Tested
- *Not all vane pumps available are shown. Call and ask to speak to a sales represetative if the model you seek is not shown here.
| Image | Item # | Mfr. Number | Rotation | in3 Per Rev. | GPM @ 1200 RPM | Max. PSI | Max. RPM | Inlet | Outlet | Port Orientation | Shaft | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | 6303287 | V201S6S1A11 | CW | 1.19 | 6 GPM | 2500 PSI | 1800 RPM | #20 SAE O-Ring | #12 SAE O-Ring | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $302.59 / EACH Ships next business day | |||
 | 6303288 | V201S7S1A11 | CW | 1.39 | 7 GPM | 2500 PSI | 1800 RPM | #20 SAE O-Ring | #12 SAE O-Ring | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $302.59 / EACH Ships next business day | |||
 | 6303289 | V201S8S1A11 | CW | 1.62 | 8 GPM | 2500 PSI | 1800 RPM | #20 SAE O-Ring | #12 SAE O-Ring | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $302.59 / EACH Ships next business day | |||
 | 6303290 | V201S9S1A11 | CW | 1.81 | 9 GPM | 2500 PSI | 1800 RPM | #20 SAE O-Ring | #12 SAE O-Ring | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $302.59 / EACH Ships next business day | |||
 | 6303291 | V201S10S1A11 | CW | 1.93 | 10 GPM | 2500 PSI | 1800 RPM | #20 SAE O-Ring | #12 SAE O-Ring | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $302.59 / EACH Ships next business day | |||
 | 6303292 | V201S11S1A11 | CW | 2.22 | 11 GPM | 2500 PSI | 1800 RPM | #20 SAE O-Ring | #12 SAE O-Ring | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $302.59 / EACH Ships next business day | |||
 | 6303293 | V201S12S1A11 | CW | 2.38 | 12 GPM | 2200 PSI | 1800 RPM | #20 SAE O-Ring | #12 SAE O-Ring | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $302.59 / EACH Ships next business day | |||
 | 6303294 | V201S13S1A11 | CW | 2.59 | 13 GPM | 2200 PSI | 1800 RPM | #20 SAE O-Ring | #12 SAE O-Ring | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $302.59 / EACH Ships next business day | |||
 | 6303295 | V201S6S1B11 | CW | 1.19 | 6 GPM | 2500 PSI | 1800 RPM | #20 SAE O-Ring | #12 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $302.59 / EACH Ships next business day | |||
 | 6303296 | V201S7S1B11 | CW | 1.39 | 7 GPM | 2500 PSI | 1800 RPM | #20 SAE O-Ring | #12 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $302.59 / EACH Ships next business day | |||
 | 6303297 | V201S8S1B11 | CW | 1.62 | 8 GPM | 2500 PSI | 1800 RPM | #20 SAE O-Ring | #12 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $302.59 / EACH Ships next business day | |||
 | 6303298 | V201S9S1B11 | CW | 1.81 | 9 GPM | 2500 PSI | 1800 RPM | #20 SAE O-Ring | #12 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $302.59 / EACH Ships next business day | |||
 | 6303299 | V201S10S1B11 | CW | 1.93 | 10 GPM | 2500 PSI | 1800 RPM | #20 SAE O-Ring | #12 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $302.59 / EACH Ships next business day | |||
 | 6303300 | V201S11S1B11 | CW | 2.22 | 11 GPM | 2500 PSI | 1800 RPM | #20 SAE O-Ring | #12 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $302.59 / EACH Ships next business day | |||
 | 6303301 | V201S12S1B11 | CW | 2.38 | 12 GPM | 2200 PSI | 1800 RPM | #20 SAE O-Ring | #12 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $302.59 / EACH Ships next business day |
