G620 SERIES
- The G620 Series back mount closed circuit sight gages provide front viewing of the fl uid level clearly delineated by a redline on white background integral to the sight glass all secured within an aluminum body
- A wetted dial thermometer provides an analog display of the fl uid temperature
- HIGH-LOW markings are stamped into the aluminum body
- Fluid level visible from front of gage (.50 inches wide)
- Viewing enhanced by redline on white background integral to sight glass
- 1.38” diameter dual scale dial thermometer, 50°F to 300°F
- Suitable for use with most hydraulic and machine lubricating oils
- Aluminum gage body and mounting bolts
- Buna N seals
- Borosilicate glass sight
- Zinc plated, steel hex nuts
- CAUTION:
- Not recommended for use with water, steam, acidic fluids, caustic fluids and volatile fluids
- If aluminum construction is selected for a water application, anodizing is recommended
- Reservoir must be drained to remove dial thermometer or loss of fluid will occur
| Image | Item # | Mfr. Number | Mounting Centers | Width | Length | Seal | Viewing Window | Material | Male Pipe | Price | Order Qty. | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1232658 | G620-03-A-1 | 3" | 0.9" | 4.62" | Buna | 1.5" x 0.5" | Aluminum | 1/2" -20 UNF | $46.45 / EACH Usually ships in 3 day(s) |
| ||||
| 1232659 | G620-04-A-1 | 4" | 0.9" | 5.62" | Buna | 2.5" x 0.5" | Aluminum | 1/2" -20 UNF | $51.69 / EACH Usually ships in 3 day(s) |
| ||||
| 1232660 | G620-05-A-1 | 5" | 0.9" | 6.62" | Buna | 3.5" x 0.5" | Aluminum | 1/2" -20 UNF | $45.25 / EACH Usually ships in 3 day(s) |
| ||||
| 1232661 | G620-06-A-1 | 6" | 0.9" | 7.62" | Buna | 4.5" x 0.5" | Aluminum | 1/2" -20 UNF | $49.59 / EACH Usually ships in 3 day(s) |
| ||||
| 1232662 | G620-07-A-1 | 7" | 0.9" | 8.62" | Buna | 5.5" x 0.5" | Aluminum | 1/2" -20 UNF | $50.61 / EACH Usually ships in 3 day(s) |
| ||||
| 1232663 | G620-08-A-1 | 8" | 0.9" | 9.62" | Buna | 6.5" x 0.5" | Aluminum | 1/2" -20 UNF | $53.23 / EACH Usually ships in 3 day(s) |
| ||||
| 1232664 | G620-12-A-1 | 12" | 0.9" | 13.62" | Buna | 10.5" x 0.5" | Aluminum | 1/2" -20 UNF | $62.57 / EACH Usually ships in 3 day(s) |
| ||||
| 1232665 | G620-18-A-1 | 18" | 0.9" | 19.62" | Buna | 16.5" x 0.5" | Aluminum | 1/2" -20 UNF | $100.61 / EACH Usually ships in 3 day(s) |
| ||||
