LSP201 SERIES
- The LSP201 Series medium pressure brass sight plug has a clear glass sight and male PTF pipe thread connection
- Designed to be an economical alternative to high performance fused sight plugs and with pressure ratings exceeding the LSP151 Series
- The LSP201 Series sight plug features a tamper resistant construction and can be accessorized with reflector and float ball
- Box quantities may apply
- Stud end sizes from 1/4 inch NPT to 2-11½ inch NPT
- Clear glass sight
- Available open view, with reflector or with reflector and float ball
- Brass construction
- Stainless Steel reflector (when applicable)
- Cork float ball (when applicable)
- Maximum operating temperature up to 180°F
- CAUTION:
- Do not use an impact wrench to install a sight plug
- Not recommended for steam applications
- Scratched glass significantly reduces the pressure rating of the sight plug
| Image | Item # | Mfr. Number | View | NPT Threads | Max PSI @ 69F | Hex | Price | Order Qty. | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | 1232752 | LSP201-03 | Open | 3/8"-18 | 415 | 0.75" | $16.37 / EACH Usually ships in 3 day(s) |
| ||||
 | 1232753 | LSP201-04 | Open | 1/2"-14 | 250 | 0.88" | $11.63 / EACH Usually ships in 3 day(s) |
| ||||
 | 1232754 | LSP201-04-01 | Reflector | 1/2"-14 | 250 | 0.88" | $11.70 / EACH Usually ships in 3 day(s) |
| ||||
 | 1232755 | LSP201-05 | Open | 3/4"-14 | 200 | 1.12" | $16.48 / EACH Usually ships in 3 day(s) |
| ||||
 | 1232756 | LSP201-05-01 | Reflector | 3/4"-14 | 200 | 1.12" | $16.96 / EACH Usually ships in 3 day(s) |
| ||||
 | 1232757 | LSP201-06 | Open | 1"-11 1/2 | 100 | 1.44" | $22.23 / EACH Usually ships in 3 day(s) |
| ||||
 | 1232758 | LSP201-06-01 | Reflector | 1"-11 1/2 | 100 | 1.44" | $22.77 / EACH Usually ships in 3 day(s) |
| ||||
 | 1232759 | LSP201-06-02 | Reflector w/ ball | 1"-11 1/2 | 100 | 1.44" | $23.16 / EACH Usually ships in 3 day(s) |
| ||||
 | 1232760 | LSP201-07 | Open | 1 1/4"-11 1/2 | 60 | 1.75" | $36.11 / EACH Usually ships in 3 day(s) |
| ||||
 | 1232761 | LSP201-07-01 | Reflector | 1 1/4"-11 1/2 | 60 | 1.75" | $36.62 / EACH Usually ships in 3 day(s) |
| ||||
 | 1232762 | LSP201-08 | Open | 1 1/2"-11 1/2 | 50 | 2" | $56.77 / EACH Usually ships in 3 day(s) |
| ||||
 | 1232763 | LSP201-08-01 | Reflector | 1 1/2"-11 1/2 | 50 | 2" | $59.37 / EACH Usually ships in 3 day(s) |
| ||||
 | 1232764 | LSP201-09 | Open | 2"-11 1/2 | 20 | 2.5" | $78.53 / EACH Usually ships in 3 day(s) |
| ||||
