  • The G607 Series front mount closed circuit sight gages provide front viewing of the fluid level clearly delineated by a redline on white background integral to the glass sight all secured within an aluminum body
  • HIGH-LOW markings are stamped into the aluminum body
  • Brass pipe adapters are provided with the sight gages for direct assembly of the sight gage to NPT couplings
  • Fluid level visible from front of gage (.50 inches wide)
  • Viewing enhanced by redline on white background integral to sight glass
  • Suitable for use with most hydraulic and machine lubricating oils
  • Aluminum gage body and mounting bolts
  • Brass pipe adapters
  • Buna N seals
  • Borosilicate glass sight
  • CAUTION:
  • Not recommended for use with water, steam, acidic fluids, caustic fluids and volatile fluids
*** Slide left / right to view more ***
ImageItem #Mfr. NumberMounting CentersWidthLengthSealViewing WindowMaterialMale PipePriceOrder Qty.
1232589G607-03-A-1-23"0.9"4.62"Buna1.5" x 0.5"Aluminum1/4" $35.89 / EACH
Usually ships in 3 day(s)
MIN ORD QTY: 4
1232590G607-04-A-1-44"0.9"5.62"Buna2.5" x 0.5"Aluminum1/2" $38.44 / EACH
Usually ships in 3 day(s)
MIN ORD QTY: 4
1232591G607-05-A-1-25"0.9"6.62"Buna3.5" x 0.5"Aluminum1/4" $37.09 / EACH
Usually ships in 3 day(s)
MIN ORD QTY: 4
1232592G607-05-A-1-35"0.9"6.62"Buna3.5" x 0.5"Aluminum3/8" $36.89 / EACH
Usually ships in 3 day(s)
MIN ORD QTY: 4
1232593G607-05-A-1-45"0.9"6.62"Buna3.5" x 0.5"Aluminum1/2" $37.76 / EACH
Usually ships in 3 day(s)
MIN ORD QTY: 4
1232594G607-06-A-1-26"0.9"7.62"Buna4.5" x 0.5"Aluminum1/4" $38.31 / EACH
Usually ships in 3 day(s)
MIN ORD QTY: 4
1232595G607-06-A-1-36"0.9"7.62"Buna4.5" x 0.5"Aluminum3/8" $39.60 / EACH
Usually ships in 3 day(s)
MIN ORD QTY: 4
1232596G607-06-A-1-46"0.9"7.62"Buna4.5" x 0.5"Aluminum1/2" $39.53 / EACH
Usually ships in 3 day(s)
MIN ORD QTY: 4
1232597G607-07-A-1-27"0.9"8.62"Buna5.5" x 0.5"Aluminum1/4" $45.47 / EACH
Usually ships in 3 day(s)
MIN ORD QTY: 4
1232598G607-07-A-1-47"0.9"8.62"Buna5.5" x 0.5"Aluminum1/2" $49.80 / EACH
Usually ships in 3 day(s)
MIN ORD QTY: 3
1232599G607-08-A-1-28"0.9"9.62"Buna6.5" x 0.5"Aluminum1/4" $48.88 / EACH
Usually ships in 3 day(s)
MIN ORD QTY: 3
1232600G607-08-A-1-48"0.9"9.62"Buna6.5" x 0.5"Aluminum1/2" $54.62 / EACH
Usually ships in 3 day(s)
MIN ORD QTY: 3
1232601G607-09-A-1-29"0.9"10.62"Buna7.5" x 0.5"Aluminum1/4" $49.83 / EACH
Usually ships in 3 day(s)
MIN ORD QTY: 3
1232602G607-09-A-1-39"0.9"10.62"Buna7.5" x 0.5"Aluminum3/8" $51.61 / EACH
Usually ships in 3 day(s)
MIN ORD QTY: 3
1232603G607-09-A-1-49"0.9"10.62"Buna7.5" x 0.5"Aluminum1/2" $51.59 / EACH
Usually ships in 3 day(s)
MIN ORD QTY: 3
