1-1/4" Keyed Shaft

1-1/4" Keyed Shaft

  • '500' Series
  • 1-1/4" Keyed Shaft
  • 1.437" x 0.313" Key
  • 4-Hole, Wheel Mount
  • 7/8-14 UNF Aligned Ports
  • 500 - Counter-Clockwise
  • High Pressure Viton Shaft Seal
  • Heavy Duty Drive Link
  • Valve-In-Rator Design
  • Pressure-Compensated Balance Plate
  • High Temperature Seals are Standard

*** Slide table left/right to view more ***

Item Order Qty. Mfr. Number Cubic Inch Disp. Shaft Keyway Max GPM Max RPM Max PSI Torque (lb-in) at Max PSI Rotation
501125W3120AAAAA White Drive Products Replacement, Clockwise Rotation, 7.2 in3/rev, 4-Hole, Wheel Mount, Aligned Ports, 7/8-14 UNF, 1-1/4" Keyed Shaft, Replaces White RE Series 501125W3120AAAAA

5951364

501125W3120AAAAA White Drive Products Replac...

$481.37/each

Usually ships in 20 weeks

501125W3120AAAAA 7.2 1-1/4" 1.437" 11.88 360 2973 2876 Clockwise
501160W3120AAAAA White Drive Products Replacement, Clockwise Rotation, 9.5 in3/rev, 4-Hole, Wheel Mount, Aligned Ports, 7/8-14 UNF, 1-1/4" Keyed Shaft, Replaces White RE Series 501160W3120AAAAA

5951367

501160W3120AAAAA White Drive Products Replac...

$481.37/each

Ships next business day

501160W3120AAAAA 9.5 1-1/4" 1.437" 15.85 375 2973 3983 Clockwise
501200W3120AAAAA White Drive Products Replacement, Clockwise Rotation, 11.9 in3/rev, 4-Hole, Wheel Mount, Aligned Ports, 7/8-14 UNF, 1-1/4" Keyed Shaft, Replaces White RE Series 501200W3120AAAAA

5951370

501200W3120AAAAA White Drive Products Replac...

$516.97/each

Usually ships in 20 weeks

501200W3120AAAAA 11.9 1-1/4" 1.437" 18.49 330 2973 4691 Clockwise
501230W3120AAAAA White Drive Products Replacement, Clockwise Rotation, 13.9 in3/rev, 4-Hole, Wheel Mount, Aligned Ports, 7/8-14 UNF, 1-1/4" Keyed Shaft, Replaces White RE Series 501230W3120AAAAA

5951373

501230W3120AAAAA White Drive Products Replac...

$516.97/each

Ships next business day

501230W3120AAAAA 13.9 1-1/4" 1.437" 18.49 290 2973 5531 Clockwise
501250W3120AAAAA White Drive Products Replacement, Clockwise Rotation, 15.7 in3/rev, 4-Hole, Wheel Mount, Aligned Ports, 7/8-14 UNF, 1-1/4" Keyed Shaft, Replaces White RE Series 501250W3120AAAAA

5951376

501250W3120AAAAA White Drive Products Replac...

$516.97/each

Usually ships in 20 weeks

501250W3120AAAAA 15.7 1-1/4" 1.437" 19.81 290 2973 6195 Clockwise
501300W3120AAAAA White Drive Products Replacement, Clockwise Rotation, 18.1 in3/rev, 4-Hole, Wheel Mount, Aligned Ports, 7/8-14 UNF, 1-1/4" Keyed Shaft, Replaces White RE Series 501300W3120AAAAA

5951379

501300W3120AAAAA White Drive Products Replac...

$557.64/each

Ships next business day

501300W3120AAAAA 18.1 1-1/4" 1.437" 21.13 250 2973 7169 Clockwise
501350W3120AAAAA White Drive Products Replacement, Clockwise Rotation, 21.1 in3/rev, 4-Hole, Wheel Mount, Aligned Ports, 7/8-14 UNF, 1-1/4" Keyed Shaft, Replaces White RE Series 501350W3120AAAAA

5951382

501350W3120AAAAA White Drive Products Replac...

$557.64/each

Usually ships in 20 weeks

501350W3120AAAAA 21.1 1-1/4" 1.437" 21.13 220 2973 8009 Clockwise
501375W3120AAAAA White Drive Products Replacement, Clockwise Rotation, 22.6 in3/rev, 4-Hole, Wheel Mount, Aligned Ports, 7/8-14 UNF, 1-1/4" Keyed Shaft, Replaces White RE Series 501375W3120AAAAA

5951385

501375W3120AAAAA White Drive Products Replac...

$594.93/each

Ships next business day

501375W3120AAAAA 22.6 1-1/4" 1.437" 19.81 200 2973 8762 Clockwise
501475W3120AAAAA White Drive Products Replacement, Clockwise Rotation, 28.2 in3/rev, 4-Hole, Wheel Mount, Aligned Ports, 7/8-14 UNF, 1-1/4" Keyed Shaft, Replaces White RE Series 501475W3120AAAAA

5951388

501475W3120AAAAA White Drive Products Replac...

$594.93/each

Usually ships in 20 weeks

501475W3120AAAAA 28.2 1-1/4" 1.437" 19.81 160 2538 9602 Clockwise
501540W3120AAAAA White Drive Products Replacement, Clockwise Rotation, 32.9 in3/rev, 4-Hole, Wheel Mount, Aligned Ports, 7/8-14 UNF, 1-1/4" Keyed Shaft, Replaces White RE Series 501540W3120AAAAA

5951391

501540W3120AAAAA White Drive Products Replac...

$672.90/each

Ships next business day

501540W3120AAAAA 32.9 1-1/4" 1.437" 19.81 140 2030 8673 Clockwise
501750W3120AAAAA White Drive Products Replacement, Clockwise Rotation, 45.6 in3/rev, 4-Hole, Wheel Mount, Aligned Ports, 7/8-14 UNF, 1-1/4" Keyed Shaft, Replaces White RE Series 501750W3120AAAAA

5951394

501750W3120AAAAA White Drive Products Replac...

$672.90/each

Usually ships in 20 weeks

501750W3120AAAAA 45.6 1-1/4" 1.437" 19.81 100 1523 9293 Clockwise

*** Slide table left/right to view more ***

Page 1 of 1
