PVH74 S10
- PVH74 Piston Pump
- Up to 4000 PSI
- 100% Tested
- Pressure Compensator
- 1800 RPM Maximum
- PVH - SAE 4-Bolt
- Series 10 includes case to inlet check valve
- *Not all models are listed. Please call us and ask for a sales representative if the model you seek is not shown here.
| Image | Item # | Mfr. Number | Rotation | in3 Per Rev | GPM @1800 RPM | Max PSI | PSI Adjustment Range | Inlet | Outlet | Case Drain | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 6191049 | PVH74C-RF-1S-10-C2531 | CW | 4.5 | 35.07 | 4000 | 2000-4000 | 2" Code 61 | 1" Code 61 | #8 O-Ring | $1,635.38 / EACH Ships next business day | |||
| 6191052 | PVH74C-LF-1S-10-C2531 | CCW | 4.5 | 35.07 | 4000 | 2000-4000 | 2" Code 61 | 1" Code 61 | #8 O-Ring | $1,635.38 / EACH Ships next business day | |||
| 6191055 | PVH74QIC-RF-1S-10-C2531 | CW | 4.5 | 35.07 | 4000 | 2000-4000 | 2" Code 61 | 1" Code 61 | #8 O-Ring | $1,635.38 / EACH Ships next business day | |||
| 6191058 | PVH74QIC-LF-1S-10-C2531 | CCW | 4.5 | 35.07 | 4000 | 2000-4000 | 2" Code 61 | 1" Code 61 | #8 O-Ring | $1,635.38 / EACH Ships next business day | |||
| 6191061 | PVH74C-RF-2S-10-C2531 | CW | 4.5 | 35.07 | 4000 | 2000-4000 | 2" Code 61 | 1" Code 61 | #8 O-Ring | $1,635.38 / EACH Ships next business day | |||
| 6191064 | PVH74C-LF-2S-10-C2531 | CCW | 4.5 | 35.07 | 4000 | 2000-4000 | 2" Code 61 | 1" Code 61 | #8 O-Ring | $1,635.38 / EACH Ships next business day | |||
| 6191067 | PVH74QIC-RF-2S-10-C2531 | CW | 4.5 | 35.07 | 4000 | 2000-4000 | 2" Code 61 | 1" Code 61 | #8 O-Ring | $1,635.38 / EACH Ships next business day | |||
| 6191070 | PVH74QIC-LF-2S-10-C2531 | CCW | 4.5 | 35.07 | 4000 | 2000-4000 | 2" Code 61 | 1" Code 61 | #8 O-Ring | $1,635.38 / EACH Ships next business day | |||
| 6191073 | PVH74C-RF-3S-10-C2531 | CW | 4.5 | 35.07 | 4000 | 2000-4000 | 2" Code 61 | 1" Code 61 | #8 O-Ring | $1,635.38 / EACH Ships next business day | |||
| 6191076 | PVH74C-LF-3S-10-C2531 | CCW | 4.5 | 35.07 | 4000 | 2000-4000 | 2" Code 61 | 1" Code 61 | #8 O-Ring | $1,635.38 / EACH Ships next business day | |||
| 6191079 | PVH74QIC-RF-3S-10-C2531 | CW | 4.5 | 35.07 | 4000 | 2000-4000 | 2" Code 61 | 1" Code 61 | #8 O-Ring | $1,635.38 / EACH Ships next business day | |||
| 6191082 | PVH74QIC-LF-3S-10-C2531 | CCW | 4.5 | 35.07 | 4000 | 2000-4000 | 2" Code 61 | 1" Code 61 | #8 O-Ring | $1,635.38 / EACH Ships next business day | |||
| 6191085 | PVH74C-RF-13S-10-C2531 | CW | 4.5 | 35.07 | 4000 | 2000-4000 | 2" Code 61 | 1" Code 61 | #8 O-Ring | $1,635.38 / EACH Ships next business day | |||
| 6191088 | PVH74C-LF-13S-10-C2531 | CCW | 4.5 | 35.07 | 4000 | 2000-4000 | 2" Code 61 | 1" Code 61 | #8 O-Ring | $1,635.38 / EACH Ships next business day | |||
| 6191091 | PVH74QIC-RF-13S-10-C2531 | CW | 4.5 | 35.07 | 4000 | 2000-4000 | 2" Code 61 | 1" Code 61 | #8 O-Ring | $1,635.38 / EACH Ships next business day |
