SINGLE ACTING - PULL
- High strength steel construction
- One piece high grade alloy bearing for side load protection and longer life
- Polyurethane cup seal helps provide for optimum performance
- External rod threads
- Internal base threads
- Used for pulling and tensioning
- Maximum Working Pressure: 10,000 PSI / 700 bar
- BVA Catalog
| Image | Item # | BVA Model# | Capacity (Tons) | Bore | Stroke | Rod Dia. | Effective Area (in2) | Oil Capacity (in3) | Collapsed Height | Extended Height | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | 8012989 | HP0205 | 2.5 Ton | 1.13" | 5" | 0.75" | 0.56 | 2.78 | 10.55" | 15.55" | Add to cart to see price Usually ships in 1 day(s) | |||
 | 8012992 | HP0505 | 5 Ton | 1.69" | 5.55" | 1.18" | 1.14 | 6.34 | 11.93" | 17.48" | Add to cart to see price Usually ships in 1 day(s) | |||
 | 8012995 | HP1006 | 10 Ton | 2.17" | 5.95" | 1.26" | 2.44 | 14.48 | 11.75" | 17.7" | Add to cart to see price Usually ships in 1 day(s) | |||
 | 8012994 | HPB1006 | 10 Ton | 2.17" | 5.95" | 1.26" | 2.44 | 14.48 | 21.02" | 28.88" | Add to cart to see price Usually ships in 1 day(s) | |||
 | 8012996 | HPB1006A | 10 Ton | 2.17" | 5.95" | 1.26" | 2.44 | 14.48 | 22.24" | 28.17" | Add to cart to see price Usually ships in 1 day(s) | |||
 | 8013934 | HPB3006A | 30 Ton | 3.35" | 6.1" | 1.97" | 6.33 | 38.63 | 42.72" | 48.82" | Add to cart to see price Usually ships in 1 day(s) |
