THREE PHASE - CAST IRON - SEVERE DUTY
- Three Phase
- NEMA Premium Energy Efficency Design
- TEFC IP 56 Protection
- VPI with Tropicalization on Stator Windings
- Felt Wiper on Inner Bearing Retainer
- Stainless Steel Hardwear
- Class H Insulation
- Drive End Shaft Ground Brush
- 40°C Ambient Temperature Rating
- 60 Month Warranty from Purchase Date
- Inverter Rated - 15:1 Constant Torque MG1 Part 31
- Complete Cast-Iron Construction
- 2-Part Epoxy Coating Paint Protection
- Dual Oversized Bearings on DE & ODE
- Labyrinth Seals Installed on DE & ODE
- Bearings Grease Chamber Pressure Relief Valve
- Regreasable Bearings
- One-Way Sintered Brass Drain
- 1.25 Service Factor to 50HP (1.15 for larger frames)
- C & D Flanges Available
- Meets IEEE 841 Standards/IEEE 45 Marine Duty
| Image | Item # | MFR Number | HP | Frame | RPM | Voltage | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 5966549 | SD3-143T-2-BR-E-1 | 1 | 143T | 3600 | 460 | $479.08 / EACH Usually ships in 1 day(s) | |||
| 5966552 | SD3-143TC-2-BR-E-1 | 1 | 143TC | 3600 | 460 | $538.70 / EACH Usually ships in 1 day(s) | |||
| 5966551 | SD3-143T-4-BR-E-1 | 1 | 143T | 1800 | 460 | $508.89 / EACH Usually ships in 1 day(s) | |||
| 5966554 | SD3-143TC-4-BR-E-1 | 1 | 143TC | 1800 | 460 | $572.06 / EACH Usually ships in 1 day(s) | |||
| 5966558 | SD3-145T-6-BR-E-1 | 1 | 145T | 1200 | 460 | $556.44 / EACH Usually ships in 1 day(s) | |||
| 5966562 | SD3-145TC-6-BR-E-1 | 1 | 145TC | 1200 | 460 | $617.48 / EACH Usually ships in 1 day(s) | |||
| 5966550 | SD3-143T-2-BR-E-1.5 | 1.5 | 143T | 3600 | 460 | $503.92 / EACH Usually ships in 1 day(s) | |||
| 5966553 | SD3-143TC-2-BR-E-1.5 | 1.5 | 143TC | 3600 | 460 | $563.54 / EACH Usually ships in 1 day(s) | |||
| 5966556 | SD3-145T-4-BR-E-1.5 | 1.5 | 145T | 1800 | 460 | $553.61 / EACH Usually ships in 1 day(s) | |||
| 5966560 | SD3-145TC-4-BR-E-1.5 | 1.5 | 145TC | 1800 | 460 | $616.77 / EACH Usually ships in 1 day(s) | |||
| 5966565 | SD3-182T-6-BR-E-1.5 | 1.5 | 182T | 1200 | 460 | $755.17 / EACH Usually ships in 1 day(s) | |||
| 5966568 | SD3-182TC-6-BR-E-1.5 | 1.5 | 182TC | 1200 | 460 | $895.71 / EACH Usually ships in 1 day(s) | |||
| 5966555 | SD3-145T-2-BR-E-2 | 2 | 145T | 3600 | 460 | $558.57 / EACH Usually ships in 1 day(s) | |||
| 5966559 | SD3-145TC-2-BR-E-2 | 2 | 145TC | 3600 | 460 | $618.19 / EACH Usually ships in 1 day(s) | |||
| 5966557 | SD3-145T-4-BR-E-2 | 2 | 145T | 1800 | 460 | $574.90 / EACH Usually ships in 1 day(s) |
