Horizontal Plastic Tanks (Short)

Horizontal Plastic Tanks (Short)

  • Single-Acting Cylinder, Power-Up, Gravity-Down, Power Unit
  • Load Holding On Port "P"
  • Horizontal Plastic Tank (5.00" Square)
  • #6 SAE O-Ring Ports
  • Relief Set At 3200 PSI, Adjustable from 1800 PSI to 3200 PSI
  • Integral Pressure Port Check Valve
  • Heavy Duty Ball-Bearing Motor
  • Heavy Duty Motor Start Switch
  • Made in the USA

*** Slide table left/right to view more ***

Item Order Qty. Mfr. Number Tank Capacity Overall Tank Length
D203T-4850-50-32 - MTE 12 VDC Power Unit, Hydraulic Circuit: Single-Acting Cylinder, Lift/Check/Dump, 1.25 Quart Capacity, Horizontal Plastic Tank, Ports are #6 SAE O-Ring, Relief is set at 3200 PSI (Adjustable From 1750 PSI to 3200 PSI), Integral Pressure Port Check Valve, Heavy-Duty Ball-Bearing Motor, Heavy-Duty Motor Start Switch. Also Replaces MTE D202T-4850-50-32.

6111101

D203T-4850-50-32 - MTE 12 VDC Power Unit, Hy...

$463.36/asmb

In stock - Ships same day

D203T-4850-50-32 1.25 Quarts 6.5"
D203T-4850-51-32 - MTE 12 VDC Power Unit, Hydraulic Circuit: Single-Acting Cylinder, Lift/Check/Dump, 1.75 Quart Capacity, Horizontal Plastic Tank, Ports are #6 SAE O-Ring, Relief is set at 3200 PSI (Adjustable From 1750 PSI to 3200 PSI), Integral Pressure Port Check Valve, Heavy-Duty Ball-Bearing Motor, Heavy-Duty Motor Start Switch. Also Replaces MTE D202T-4850-51-32.

6111103

D203T-4850-51-32 - MTE 12 VDC Power Unit, Hy...

$456.50/asmb

In stock - Ships same day

D203T-4850-51-32 1.75 Quarts 8.5"
D203T-4850-52-32 - MTE 12 VDC Power Unit, Hydraulic Circuit: Single-Acting Cylinder, Lift/Check/Dump, 2.50 Quart Capacity, Horizontal Plastic Tank, Ports are #6 SAE O-Ring, Relief is set at 3200 PSI (Adjustable From 1750 PSI to 3200 PSI), Integral Pressure Port Check Valve, Heavy-Duty Ball-Bearing Motor, Heavy-Duty Motor Start Switch. Also Replaces MTE D202T-4850-52-32.

6111105

D203T-4850-52-32 - MTE 12 VDC Power Unit, Hy...

$459.51/asmb

In stock - Ships same day

D203T-4850-52-32 2.50 Quarts 11.0"
D203T-4850-53-32 - MTE 12 VDC Power Unit, Hydraulic Circuit: Single-Acting Cylinder, Lift/Check/Dump, 3.50 Quart Capacity, Horizontal Plastic Tank, Ports are #6 SAE O-Ring, Relief is set at 3200 PSI (Adjustable From 1750 PSI to 3200 PSI), Integral Pressure Port Check Valve, Heavy-Duty Ball-Bearing Motor, Heavy-Duty Motor Start Switch. Also Replaces MTE D202T-4850-53-32.

6111107

D203T-4850-53-32 - MTE 12 VDC Power Unit, Hy...

$466.19/asmb

In stock - Ships same day

D203T-4850-53-32 3.50 Quarts 14.0"
D203T-4850-54-32 - MTE 12 VDC Power Unit, Hydraulic Circuit: Single-Acting Cylinder, Lift/Check/Dump, 5.00 Quart Capacity, Horizontal Plastic Tank, Ports are #6 SAE O-Ring, Relief is set at 3200 PSI (Adjustable From 1750 PSI to 3200 PSI), Integral Pressure Port Check Valve, Heavy-Duty Ball-Bearing Motor, Heavy-Duty Motor Start Switch. Also Replaces MTE D202T-4850-54-32.

6111109

D203T-4850-54-32 - MTE 12 VDC Power Unit, Hy...

$468.26/asmb

In stock - Ships same day

D203T-4850-54-32 5.00 Quarts 20.0"

*** Slide table left/right to view more ***

Page 1 of 1
