Pressure & Tank Power Units

• Gas Engine Power Units
• Battery included on electric start models
• Unit packed and shipped in quality wooden crate
• Painted blue
• Return filter: 10 Micron (filler/breather integral), #12 O-Ring Port
• Suction filter: 100 Mesh with 5 PSI bypass
• Ports: #12 O-Ring (Pressure & Tank)
• Gauge: Liquid filled S.S. Case 0-3000 on 1500 PSI maximum power units, Liquid filled S.S. Case 0-5000 on 3000 PSI maximum power units
• Tank:10 gallon, fully baffled, 12 gauge steel
• Level sight/temperature gauge standard
• Relief Valve: Preset to power units' maximum pressure capability (see chart)
• Pumps: high performance pressure balanced aluminum body gear pump or rugged cast iron fixed clearance "high-low" pumps
• Tank drain plugs: #8 O-Ring (x2), use for motor case drains, returns, or drains
• Fully tested before shipment, engine oil on board
• All-weather 10 weight hydraulic oil recommended, ATF satisfactory
• Replacement components available from stock
• *Indicates the use of a "high-low" pump, high volume at low pressure, low volume at high pressure
