- 2 to 6 work sections per monoblock
- Single load hold check per monoblock
- Open or closed center capability
- Hard chrome plated spools, body is high strength cast iron, and seals are Buna "N"
- Compact construction
- Paralllel circuit
- Balanced interchangeable spools
- Negative overlapping of the spool
- Max flow rate 12 GPM
- Max PSI at "P" port=3600 PSI
- Max PSI at "A" or "B" ports-4600 PSI
- Max PSI back-pressure at "T" port=430 PSI
- Max operating temperature=180°F
- Filter oil to 30 micron or better
- Leakage (1450 PSI, Temperature at 120°F)
Average: 0.366 In3/minute
Maximum: 0.732 In3/minute - Adjustable direct operated relief valve
- Power beyond capability
- Handle can be mounted vertical or horizontal
