PROJECTILE VERIFICATION SYSTEMS
- The Projectile Verification System ensures that no projectile is left in a hose, tube or pipe
- The system is designed for various applications but is most beneficial in high-volume fabrication facilities where spend and efficiency are a priority
- The system provides peace-of-mind that each line is cleaned according to specifications and that each projectile has successfully exited the assembly
- Three Cleaning modes allow specific cleaning for various levels of contamination
- Air Requirements:
- 80 PSI Minimum to 110 PSI Maximum
- 1/2" ID air hose to ensure 55 SCFM air flow
- Features & Benefits:
- Projectile Counting
- Fault Counting
- Regulator & Gauge
- 24-Volt DC Power Supply
- Bench Mount Connection
- HL-PVS Connection
- Color Touchscreen
- Flexible Sequence Options
- Data Logging
- Onscreen Indicator Lights
- Optional Ethernet Cable Connection
- 7" Human-Machine Interface (HMI) Screen
- 7-Year battery back-up for HMI Touchscreen
- 4 Cleaning modes: Normal Clean, Air Purge +1 Projectile, Air Purge +2 Projectiles, and Timed Air Blow
| Image | Item # | Mfr. Number | Item | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|
 | Call For Price Available | ||||||
 | 2184086 | UC-HL-PVS | 2" Hand Held Launcher | $1,704.09 / EACH Ships next business day |
