  • Single load hold check
  • Open center only
  • Hard chrome plated spools, body is high strength cast iron, and seals are Buna "N"
  • Compact construction (7.34" Long, 3.35" Wide)
  • Balanced interchangeable spools
  • Negative overlapping of the spool
  • Max flow rate 10 GPM
  • Max PSI at "P" port=3600 PSI
  • Max PSI at "A" or "B" ports-4600 PSI
  • Max PSI back-pressure at "T" port=430 PSI
  • Max operating temperature=180°F
  • Filter oil to 30 micron or better
  • Leakage (1450 PSI, Temperature at 120°F)
    Average: 0.366 In3/minute
    Maximum: 0.732 In3/minute
  • Adjustable direct operated relief valve
  • Handle can be mounted vertical or horizontal
*** Slide left / right to view more ***
ImageItem #Number of SpoolsPortsPriceOrder Qty.
71531061 Spool#8 SAE O-Ring $109.85 / EACH
In Stock - Ships same day
