DUAL RELIEFPLUS - 40 GPM RELIEF VALVE
- Hydraulic couplers Can be Mounted Directly to the Manifold
- Removes Leak Points
- Easily Plumbed
- Professional and Clean Appearance
- Operating Pressure: 3500 PSI Maximum
- Flow: 40 GPM
- Ports: #16 SAE O-Ring P & T Ports, #6 SAE O-Ring Gauge Port
- Relief Valve: Pilot Operated, Preset at 3000 PSI, 300-3500 Adjustment
- Pressure Gauge: Liquid Filled, 0-5000 PSI, Dual Scale Includes Bar
- Installation: Unrestricted
- Hardware Included: Socket Head Cap Screws, Washers, and Nuts
- Temperature Range: -40°F to +212°F
- Hydraulic System: All, Fixed and Variable Displacement Pumps
- construction: Aircraft Grade 6061 Aluminum
- Primarily Used on Trucks to Limit System Working Pressure
- Used on Any System Where a Pressure Limiting Device is Required
| Image | Item # | Description | Price | Order Qty. | ||
|---|---|---|---|---|---|---|
| 9502868 | DUAL RELIEFPLUS 40 GPM RELIEF VALVE / RELIEF / GAUGE, #16 SAE O-RING PORTS, 3500 PSI MAXIMUM OPERATING PRESSURE, PILO... | $603.73 / EACH In stock - Ships same day | |||
 | 9502896 | DUAL RELIEFPLUS 40 GPM RELIEF VALVE / RELIEF / GAUGE / SHUTOFF, #16 SAE O-RING PORTS, 3500 PSI MAXIMUM OPERATING PRES... | $761.52 / EACH In stock - Ships same day |
