DIGITAL WIRELESS CONTROLS

Instant digital signal eliminates delays
Potted electronics resist vibration & corrosion
Program up to 40 transmitters per receiver
Great for electro-hydraulic (DC) power units, DC powered wincehs, directional control valves on any DC actuated system
Can be wired in parallel with existing hand controllers
Excellent range: up to 1000 feet depending on mounting location
Internal spring antenna limits range to 50-200 feet
Outputs/all functions are momentary
User programs transmitter to receiver
Comes complete with wiring instructions
10 AMPs maximum input power
5 AMPs maximum per output
Overload protected
Microprocessor controlled digital addressing provides a 1-in-6 million address
No DIP switches to set
418 MHz operating frequency
Accepts 6 VDC to 28 VDC for input power
FCC approved
Double-pole function: the double-pole output simultaneously fires when any button is pressed. This output is typically used on a motor start switch, a dump valve or any alike application.
Variations, like latching functions, of this product are available
If you do not see the controller desired listed below, please contact us and ask to speak to a sales representative!
