AUTOLOADER

Carousel AutoLoader is the most comprehensive automatic prjectile loading, launching, & verifications system on the market today
Designed for High-volume productions facilities
This unit can be integrated into an automatic assembly line to clean hoses, tubes, or hydraulic assemblies
It comes equipped with four cleaning modes to meet common cleaning procedures: Normal Clean, Air Purge +1 Projectile, Air Purge +2 Projectiles, & Adjustable Times Projectile Launcher without Verifications (perfect for cleaning tube bundles)
These cleaning modes address the most common cleaning issues for purging large dirt particles or liquid residue form hydraulic lines
The Built-in Programmable Logic Controller (PLC) effortlessly guides the user through the cleaning process & also logs fired & verified projectiles or faults
Features & Benefits:
Automatic projectile loading, firing & verification
Removes internal contamination form hoses, tubes or pipes quickly and efficiently in a productjion environment
Fully integratable in automated tube manufacturing processes
Verifies projectile has exited hose, tube or pipe and ented the Containment Barrel along with expelled contamination
Cleans hoses, tubes & pipes with an internal diameter of 1/4" (6mm) through 1" (25mm)
Easy change-out between 10 Hopper Box options, each handing one projectile size from 6mm to 33mm in diameter
Foot pedal firing device and/or hand held firing device options
Containment Barrel made of plastic and has a stainless steel chute assembly with green, yellow, and red lights to indicate system and projectile mode (read, firing, verified)
