SLIDING HAND VALVE
- 4-Way, 3-Position
- Manual-Operated
- Rotary Disk, Direct-Acting Type
- Recommended for stationary air cylinders, arbor presses, and/or as a throttling valve for positioning air cylinder
- Inlet is closed to pressure
- Outlet is closed to exhaust
- 0-140 PSI Operating Pressure Range
- 213 PSI Proof Pressure
- 41°F to 140°F Operating Temperature
| Image | Item # | NPTF Threads | Ports | PSI Range | Proof Pressure | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|---|---|
| 2551006 | 1/4" | Side | 0-140 PSI | 213 PSI | $162.29 / EACH Usually ships in 5 day(s) | |||
| 2551009 | 3/8" | Side | 0-140 PSI | 213 PSI | $162.29 / EACH Usually ships in 5 day(s) | |||
| 2551012 | 1/2" | Side | 0-140 PSI | 213 PSI | $162.29 / EACH Usually ships in 5 day(s) | |||
| 2551015 | 1/4" | Bottom | 0-140 PSI | 213 PSI | $77.28 / EACH Usually ships in 5 day(s) | |||
| 2551018 | 3/8" | Bottom | 0-140 PSI | 213 PSI | $77.28 / EACH Usually ships in 5 day(s) |
