  • 15GPM Valves 30 ft-lbs Cartridge Valve Torque Requirements
  • 30&40GPM Valves 90 ft-lbs Cartridge Valve Torque Requirements
  • 4-6 ft-lbs Coil Nut Torque Requirements
  • -40 Degree F to +250 Degree F
  • Coil Immersion Proof, Weatherproof, and Thermal Shock Proof
  • No External Metal Shell on Coil
  • Continuous Duty
  • 20' Wiring Harness
  • 16 Gauge Wire
  • Shielded Wire
  • IP69 Deutsch Connectors
  • 3.25"X2.25"X1.5" Black Switch Box
  • Easily Adjustable Bail Mount
  • Heavy Duty 10 Amp Long Bat Detent Switch
  • Red Switch Cover
  • Indicator Light
  • 3' Switch Box Wiring Harness
  • 6' Power Cable
  • 10 Amp Fuse Kit with Instructions
  • (10) 7.5" Cable Ties
*** Slide left / right to view more ***
ImageItem #CircuitMaximum FlowMaximum PressureAmpVoltagePort SizePriceOrder Qty.
9504615Normally Open15 GPM3500 PSI1.812 VDC#8 SAE O-Ring $149.53 / EACH
Ships same day
9504616Normally Closed15 GPM3500 PSI1.812 VDC#8 SAE O-Ring $142.01 / EACH
Ships same day
9504617Normally Open40 GPM3000 PSI1.812 VDC#12 SAE O-Ring $187.78 / EACH
Ships same day
9504618Normally Closed30 GPM3500 PSI1.812 VDC#12 SAE O-Ring $182.42 / EACH
Ships same day
