12 GPM 12 VDC ELECTRIC DIRECTIONAL VALVE W/ CONTROL KITS
- Used to control direction of cylinders or motors, depending on application
- Can be used on most mobile equipment, including ag equipment, tow trucks, tractors, and bale beds.
- 12 GPM Maximum Flow
- 3600 PSI Max at "P" Port
- 4600 PSI Max at "A" or "B" Ports
- 290 PSI Max back-pressure at "T" Port
- Adjustable Relief Valve 1300-3000 PSI
- Relief set at 2200 PSI
- DIN 12 VDC Coils, 36 Watts, 3 Amps
- Switch box features easily adjustable bail mount
- Heavy duty long bat handle momentary switches
- Switches are color coded
- Switch box has 3' wiring harness and 6' power cable
- 18 gauge shielded wire
- IP69 Deutsch Connectors
- IP65 Coil Connectors
- IP65 DIN Connectors
- 10 Amp fuse kit
- 20' wiring harness
- 3' Valve harness
| Image | Item # | Sections | # of Switches | Circuit | Tank & Pressure Ports | Work Ports | Power Beyond | Switch Colors | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | 9504510 | Double Acting Cylinder | 1 | Open Center | #8 SAE | #8 SAE | Yes | Red | $714.39 / EACH Usually ships in 1 day(s) | |||
 | 9504511 | Double Acting Cylinder | 1 | Closed Center | #8 SAE | #8 SAE | No | Red | $716.92 / EACH Usually ships in 1 day(s) | |||
| 9504446 | Double Acting Cylinder | 2 | Open Center | #8 SAE | #8 SAE | Yes | Red / White | $1,073.91 / EACH Usually ships in 1 day(s) | |||
| 9504447 | Double Acting Cylinder | 2 | Closed Center | #8 SAE | #8 SAE | No | Red / White | $1,076.13 / EACH Usually ships in 1 day(s) | |||
 | 9504470 | Double Acting Cylinder | 3 | Open Center | #8 SAE | #8 SAE | Yes | Red / White / Blue | $1,453.07 / EACH Usually ships in 1 day(s) | |||
 | 9504471 | Double Acting Cylinder | 3 | Closed Center | #8 SAE | #8 SAE | No | Red / White / Blue | $1,455.28 / EACH Usually ships in 1 day(s) | |||
 | 9504486 | Double Acting Cylinder | 4 | Open Center | #8 SAE | #8 SAE | Yes | Red / White / Blue / Green | $1,838.38 / EACH Usually ships in 1 day(s) | |||
 | 9504487 | Double Acting Cylinder | 4 | Closed Center | #8 SAE | #8 SAE | No | Red / White / Blue / Green | $1,840.60 / EACH Usually ships in 1 day(s) |
