BYPASS-TYPE REGULATOR - PRESSURE COMPENSATED - FIXED
- Mechanical Flow Control Valves
- Bypass Flow Regulators
- Pressure Compensated - Fixed
- The valve maintain a constant flow within specified accuracies from (1) to (3) regardless of downstream load pressure at (3) or bypass leg (2)
- When flow produces a minimum predetermined pressure differential across the compensator spool control orifice, the spool shifts against the spring force to throttle the flow and maintain the priority flow setting
- Reverse flow is not regulated
- Pressure-compensated
- Quiet response
- Bypass port (2) may be fully pressurized
- Industry common cavity
| Image | Item # | Mfr. Number | GPM | PSI | Size | Seal | Price | Order Qty. | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | 7015139 | DFR-100-3-N-075 | 0.75 | 3000 | 10 | Buna | $35.19 / EACH Usually ships in 7-8 week(s) |
| ||||
 | 7015140 | DFR-100-3-N-100 | 1 | 3000 | 10 | Buna | $35.19 / EACH Usually ships in 7-8 week(s) |
| ||||
 | 7015141 | DFR-100-3-N-150 | 1.5 | 3000 | 10 | Buna | $35.19 / EACH Usually ships in 7-8 week(s) |
| ||||
 | 7015142 | DFR-100-3-N-200 | 2 | 3000 | 10 | Buna | $35.19 / EACH Usually ships in 7-8 week(s) |
| ||||
 | 7015143 | DFR-100-3-N-250 | 2.5 | 3000 | 10 | Buna | $35.19 / EACH Usually ships in 7-8 week(s) |
| ||||
 | 7015144 | DFR-100-3-N-300 | 3 | 3000 | 10 | Buna | $35.19 / EACH Usually ships in 7-8 week(s) |
| ||||
 | 7015145 | DFR-100-3-N-350 | 3.5 | 3000 | 10 | Buna | $35.19 / EACH Usually ships in 7-8 week(s) |
| ||||
 | 7015146 | DFR-100-3-N-400 | 4 | 3000 | 10 | Buna | $35.19 / EACH Usually ships in 7-8 week(s) |
| ||||
 | 7015147 | DFR-100-3-N-450 | 4.5 | 3000 | 10 | Buna | $35.19 / EACH Usually ships in 7-8 week(s) |
| ||||
 | 7015148 | DFR-100-3-N-500 | 5 | 3000 | 10 | Buna | $35.19 / EACH Usually ships in 7-8 week(s) |
| ||||
 | 7015149 | DFR-100-3-N-600 | 6 | 3000 | 10 | Buna | $35.19 / EACH Usually ships in 7-8 week(s) |
| ||||
