4W2P TANDEM CENTER
- Solenoid Operated Directional control valves allow fluid to flow into different paths from one or more sources. The direction of fluid flow control is controlled through a manual or electrical spool.
- 4 Way 2 Position
- Direct Acting Spool
- Tandem Center
- When De-Energized, the valve allows flow between (2) and (4), and blocks flow at ports (1) and (3).
- When Energized, the valve allows flow from (2) to (3) and (1) to (4).
- Hardened parts for long life
- Efficient wet-armature construction
- Cartridges are voltage interchangeable
- Manual override option
- Industry common Cavity
- Unitized, molded coin design
- Continuous duty rated solenoid
- Optional coil voltages and terminations
- Optinal "I" Coil: Weatherproof, Thermal Shock, Immersion Safe
- Operation of Manual Override Option is located on the Product Details Technical Information sheet located on each individual parts page.
| Image | Item # | Mfr. Number | GPM | PSI | Size | Seals | Options | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
 | 7010339 | PQ-S4C-00 | 4 | 3000 | 3/4-16 | Buna | - | $44.00 / EACH Usually ships in 11 week(s) | |||
 | 7010340 | PQ-S4C-0M | 4 | 3000 | 3/4-16 | Buna | Detent | $71.00 / EACH Usually ships in 11 week(s) | |||
 | 7010341 | PQ-S4C-B1 | 4 | 3000 | 3/4-16 | Buna | Non-Detent | $71.00 / EACH Usually ships in 11 week(s) | |||
 | 7010342 | PQ-S4C-V0 | 4 | 3000 | 3/4-16 | Viton | - | $50.25 / EACH Usually ships in 11 week(s) | |||
 | 7010343 | PQ-S4C-V1 | 4 | 3000 | 3/4-16 | Viton | Non-Detent | $77.25 / EACH Usually ships in 11 week(s) | |||
 | 7010344 | PQ-S4C-VM | 4 | 3000 | 3/4-16 | Viton | Detent | $77.25 / EACH Usually ships in 11 week(s) | |||
 | 7010385 | DG-S4C-00 | 8 | 3000 | 7/8-14 | Buna | - | $51.25 / EACH In stock - Ships same day | |||
 | 7010545 | DG-S4C-0M | 8 | 3000 | 7/8-14 | Buna | Detent | $79.25 / EACH Usually ships in 11 week(s) | |||
 | 7010546 | DG-S4C-B1 | 8 | 3000 | 7/8-14 | Buna | Non-Detent | $79.25 / EACH Usually ships in 11 week(s) | |||
 | 7010547 | DG-S4C-V0 | 8 | 3000 | 7/8-14 | Viton | - | $57.50 / EACH Usually ships in 11 week(s) | |||
 | 7010548 | DG-S4C-V1 | 8 | 3000 | 7/8-14 | Viton | Non-Detent | $85.50 / EACH Usually ships in 11 week(s) | |||
 | 7010549 | DG-S4C-VM | 8 | 3000 | 7/8-14 | Viton | Detent | $85.50 / EACH Usually ships in 11 week(s) | |||
 | 7010550 | HG-S4C-00 | 8 | 4000 | 7/8-14 | Buna | - | $61.50 / EACH Usually ships in 11 week(s) | |||
 | 7010551 | HG-S4C-V0 | 8 | 4000 | 7/8-14 | Viton | - | $67.75 / EACH Usually ships in 11 week(s) |
