  • Proportional Control valves generate a variable pressure in response to a PWM (Pulse Width Modulated) current signal.
  • 3 Way Flow Control
  • Pressure Compensated - Normally Closed - Spool
  • Valve maintains a constant flow rate out of (1) regardless of load pressure variations in the circuit downstream of (3) and regardless bypass pressure variations in the circuit down stream of (2)
  • Excess flow bypasses out of (2)
  • When coil is not energized, there is no regulated flow out of (1)
  • Hardened parts for long life
  • Industry common cavity
  • Excellent linearity and low hysteresis characteristics
  • Cartridges are voltage interchangeable
  • Optional coil voltages and terminations available
  • Unitized, molded coil design
  • Continuous duty rated solenoid
  • Operation of Manual Override Option is located on the Product Details Technical Information sheet located on each individual parts page.
*** Slide left / right to view more ***
ImageItem #Mfr. NumberGPMPSISizeSealOptionPriceOrder Qty.
7011892EU-F3G-CS1635001 1/16-14BunaScrew Type Override Knob, Up to 60 l/min $229.25 / EACH
In stock - Ships same day
