  • Mechanical Pressure Control Valves
  • Sequence
  • 2 Way Normally Open - External Pilot & Drain
  • The valve in neutral (un-piloted), allows flow between (3) and (2) bidirectional
  • or The valve blocks flow at ports (3) and (2)
  • The spring chamber is constantly vented at (1)
  • On attainment of a predetermined pressure at (4), the cartridge shifts to close (3) to (2)
  • Note that the backpressure value at (1) must be added to the selected pressure setting to determine pilot pressure necessary to open valve
  • Optional spring ranges to 1500 PSI (103 bar)
  • Hardened parts for long life
  • Industry common cavity
*** Slide left / right to view more ***
ImageItem #Mfr. NumberGPMPSISizeSealOptionsPressure RangePriceOrder Qty.
7011155DG-PSO-00-04251030007/8-14Buna50-425 PSI Press Range $55.00 / EACH
Available
7011156DG-PSO-00-15001030007/8-14Buna425-1500 PSI Press Range $55.00 / EACH
Usually ships in 4 week(s).
Expedite available.
7012109DG-PSO-0I-04251030007/8-14BunaInternal Adjust50-425 PSI Press Range $55.00 / EACH
Usually ships in 4 week(s).
Expedite available.
7012110DG-PSO-0I-15001030007/8-14BunaInternal Adjust425-1500 PSI Press Range $55.00 / EACH
Usually ships in 4 week(s).
Expedite available.
7012111DG-PSO-0K-04251030007/8-14BunaOverride Knob50-425 PSI Press Range $60.50 / EACH
Usually ships in 4 week(s).
Expedite available.
7012112DG-PSO-0K-15001030007/8-14BunaOverride Knob425-1500 PSI Press Range $60.50 / EACH
Usually ships in 4 week(s).
Expedite available.
7012113DG-PSO-V0-04251030007/8-14Viton50-425 PSI Press Range $58.50 / EACH
Usually ships in 4 week(s).
Expedite available.
7012114DG-PSO-V0-15001030007/8-14Viton425-1500 PSI Press Range $58.50 / EACH
Usually ships in 4 week(s).
Expedite available.
7012115DG-PSO-VI-04251030007/8-14VitonInternal Adjust50-425 PSI Press Range $58.50 / EACH
Usually ships in 4 week(s).
Expedite available.
7012116DG-PSO-VI-15001030007/8-14VitonInternal Adjust425-1500 PSI Press Range $58.50 / EACH
Usually ships in 4 week(s).
Expedite available.
7012117DG-PSO-VK-04251030007/8-14VitonOverride Knob50-425 PSI Press Range $64.00 / EACH
Usually ships in 4 week(s).
Expedite available.
7012118DG-PSO-VK-15001030007/8-14VitonOverride Knob425-1500 PSI Press Range $64.00 / EACH
Usually ships in 4 week(s).
Expedite available.
7012133DG-PTO-00-00501030007/8-14Buna50 PSI Spring Bias $55.50 / EACH
Usually ships in 4 week(s).
Expedite available.
7012134DG-PTO-00-01801030007/8-14Buna180 PSI Spring Bias $55.50 / EACH
Usually ships in 4 week(s).
Expedite available.
7012135DG-PTO-V0-00501030007/8-14Viton50 PSI Spring Bias $55.50 / EACH
Usually ships in 4 week(s).
Expedite available.
   Page of 2
