  • Mechanical Directional Control Valves
  • Pilot to Shift
  • 3 Way Open Transition
  • In neutral the valve allows flow between ports (3) and (4), port (2) is blocked
  • With application of a remote pilot signal at (5), the valve's spool shifts to allow flow between ports (2) and (3), while port (4) is blocked.
  • During transition ports (2), (3), and (4) are open
  • The spring chamber is vented to the tank through port (1)
  • The vented spring chamber allows the valve to be fully pressurized at ports (2), (3), and (4) without affecting required pilot preasure
  • Pressure at (1) will affect required pilot pressure
  • Hardened parts for long life
  • Industry common cavity
*** Slide left / right to view more ***
ImageItem #Mfr. NumberGPMPSISizeSealCrack PressurePriceOrder Qty.
7011263SO-PTS-00-00704035001 5/16Buna70 PSI $76.50 / EACH
Usually ships in 4 week(s).
Expedite available.
7011261SO-PTS-00-01504035001 5/16Buna150 PSI $80.00 / EACH
Available
7011264SO-PTS-V0-00704035001 5/16Viton70 PSI $81.00 / EACH
Usually ships in 4 week(s).
Expedite available.
7011265SO-PTS-V0-01504035001 5/16Viton150 PSI $84.50 / EACH
Usually ships in 4 week(s).
Expedite available.
