  • Mechanical Directional Control Valves
  • Pilot to Shift
  • 3 Way Internal Pilot & External Drain
  • The valve in neutral (un-piloted), allows flow between (3) and (2) bi-directionally, while blocking at (4)
  • The spring chamber is constantly vented at (1)
  • On attainment of a predetermined pressure at (4), the cartridge shifts to close (3) to (2), while opening (4) to (3)
  • Note: that the backpressure valve at (1) must be added to the selected pressure setting to determine pilot pressure necessary to shift valve to second position
  • Hardened parts for long life
  • Industry common cavity
*** Slide left / right to view more ***
ImageItem #Mfr. NumberGPMPSISizeSealCrack PressurePriceOrder Qty.
7012184DG-PDI-00-00551030007/8-14Buna55 PSI $55.00 / EACH
Usually ships in 5 week(s).
Expedite available.
7012185DG-PDI-00-00801030007/8-14Buna80 PSI $55.00 / EACH
Usually ships in 5 week(s).
Expedite available.
7012186DG-PDI-00-01601030007/8-14Buna160 PSI $55.00 / EACH
Usually ships in 5 week(s).
Expedite available.
7012187DG-PDI-V0-00551030007/8-14Viton55 PSI $58.50 / EACH
Usually ships in 5 week(s).
Expedite available.
7012188DG-PDI-V0-00801030007/8-14Viton80 PSI $58.50 / EACH
Usually ships in 5 week(s).
Expedite available.
7012189DG-PDI-V0-01601030007/8-14Viton160 PSI $58.50 / EACH
Usually ships in 5 week(s).
Expedite available.
Page 1 of 1
