  • Mechanical Directional Control Valves
  • Pilot Operated Check Valves
  • Pilot to Close
  • The valve allows flow to pass from (3) to (2) and blocks flow from (2) to (3) when sufficient pressure is applied at (1)
  • The cartridge has a 2:1, 4:1, or 6:1 pilot ratio, meaning that at least one half of the load pressure held at (3) is required at (1) to close the valve
  • The check is spring biased to assure holding in static or no-load conditions
  • Hardened parts for long life
  • Industry common cavity
*** Slide left / right to view more ***
ImageItem #Mfr. NumberGPMPSISizeSealRatioCrack PressurePriceOrder Qty.
7012298DF-CPD-04-00151035007/8-14Buna4:115 PSI $27.00 / EACH
Usually ships in 4 week(s).
Expedite available.
7012299DF-CPD-04-00251035007/8-14Buna4:125 PSI $27.00 / EACH
Usually ships in 4 week(s).
Expedite available.
7012300DF-CPD-04-00501035007/8-14Buna4:150 PSI $27.00 / EACH
Usually ships in 4 week(s).
Expedite available.
7012301DF-CPD-04-00751035007/8-14Buna4:175 PSI $27.00 / EACH
Usually ships in 4 week(s).
Expedite available.
7012302DF-CPD-04-01001035007/8-14Buna4:1100 PSI $27.00 / EACH
Usually ships in 4 week(s).
Expedite available.
7012303DF-CPD-06-00151035007/8-14Buna6:115 PSI $27.00 / EACH
Usually ships in 4 week(s).
Expedite available.
7012304DF-CPD-06-00251035007/8-14Buna6:125 PSI $27.00 / EACH
Usually ships in 4 week(s).
Expedite available.
7012305DF-CPD-06-00501035007/8-14Buna6:150 PSI $27.00 / EACH
Usually ships in 4 week(s).
Expedite available.
7012306DF-CPD-06-00751035007/8-14Buna6:175 PSI $27.00 / EACH
Usually ships in 4 week(s).
Expedite available.
7012307DF-CPD-06-01001035007/8-14Buna6:1100 PSI $27.00 / EACH
Usually ships in 4 week(s).
Expedite available.
7012308DF-CPD-V4-00151035007/8-14Viton4:115 PSI $29.75 / EACH
Usually ships in 4 week(s).
Expedite available.
7012309DF-CPD-V4-00251035007/8-14Viton4:125 PSI $29.75 / EACH
Usually ships in 4 week(s).
Expedite available.
7012310DF-CPD-V4-00501035007/8-14Viton4:150 PSI $29.75 / EACH
Usually ships in 4 week(s).
Expedite available.
7012311DF-CPD-V4-00751035007/8-14Viton4:175 PSI $29.75 / EACH
Usually ships in 4 week(s).
Expedite available.
7012312DF-CPD-V4-01001035007/8-14Viton4:1100 PSI $29.75 / EACH
Usually ships in 4 week(s).
Expedite available.
