G617 SERIES
- The G617 Series front mount closed circuit sight gages provide front viewing of the fluid level clearly delineated by a redline on white background integral to the sight glass all secured within an aluminum body
- Brass pipe adapters are provided with each sight gage for assembly of the sight gage to NPT couplings
- Integral to the sight gage body is a wetted dial thermometer providing direct reading of the fl uid temperature
- HIGH-LOW markings are stamped into the aluminum body
- Fluid level visible from front of gage (.50 inches wide)
- Viewing enhanced by redline on white background integral to sight glass
- 1.38” diameter dual scale dial thermometer, 50°F to 300°F
- Suitable for use with most hydraulic and machine lubricating oils
- Aluminum gage body and mounting bolts
- Brass pipe adapters
- Buna N seals
- Borosilicate glass sight
- CAUTION:
- Not recommended for use with water, steam, acidic fluids, caustic fluids and volatile fluids
- If aluminum construction is selected for a water application, anodizing is recommended
- Reservoir must be drained to remove dial thermometer or loss of fluid will occur
| Image | Item # | Mfr. Number | Mounting Centers | Width | Length | Seal | Viewing Window | Material | Male Pipe | Price | Order Qty. | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1232647 | G617-05-A-1-2 | 5" | 0.9" | 6.62" | Buna | 3.5" x 0.5" | Aluminum | 1/4" | $65.51 / EACH Usually ships in 3 day(s) |
| ||||
| 1232648 | G617-05-A-1-3 | 5" | 0.9" | 6.62" | Buna | 3.5" x 0.5" | Aluminum | 3/8" | $67.99 / EACH Usually ships in 3 day(s) |
| ||||
| 1232649 | G617-05-A-1-4 | 5" | 0.9" | 6.62" | Buna | 3.5" x 0.5" | Aluminum | 1/2" | $67.99 / EACH Usually ships in 3 day(s) |
| ||||
| 1232650 | G617-06-A-1-4 | 6" | 0.9" | 7.62" | Buna | 4.5" x 0.5" | Aluminum | 1/2" | $76.90 / EACH Usually ships in 3 day(s) |
| ||||
| 1232651 | G617-09-A-1-4 | 9" | 0.9" | 10.62" | Buna | 7.5" x 0.5" | Aluminum | 1/2" | $80.03 / EACH Usually ships in 3 day(s) |
| ||||
| 1232652 | G617-10-A-1-4 | 10" | 0.9" | 11.62" | Buna | 8.5" x 0.5" | Aluminum | 1/2" | $81.70 / EACH Usually ships in 3 day(s) |
| ||||
| 1232653 | G617-12-A-1-2 | 12" | 0.9" | 13.62" | Buna | 10.5" x 0.5" | Aluminum | 1/4" | $83.16 / EACH Usually ships in 3 day(s) |
| ||||
| 1232654 | G617-12-A-1-4 | 12" | 0.9" | 13.62" | Buna | 10.5" x 0.5" | Aluminum | 1/2" | $83.77 / EACH Usually ships in 3 day(s) |
| ||||
| 1232655 | G617-15-A-1-4 | 15" | 0.9" | 16.62" | Buna | 13.5" x 0.5" | Aluminum | 1/2" | $96.69 / EACH Usually ships in 3 day(s) |
| ||||
| 1232656 | G617-18-A-1-4 | 18" | 0.9" | 19.62" | Buna | 16.5" x 0.5" | Aluminum | 1/2" | $105.48 / EACH Usually ships in 3 day(s) |
| ||||
| 1232657 | G617-24-A-1-4 | 24" | 0.9" | 25.62" | Buna | 22.5" x 0.5" | Aluminum | 1/2" | $137.05 / EACH Usually ships in 3 day(s) |
| ||||
